- Page 3 Screw x40pcs HDMI splitter extender HDMI splitter extender User manual DC12V/5A TX x1pcs RX x8pcs x1pcs x1pcs IR blaster extension IR Receiver extension Terminal block Mounting brackets Mounting brackets cable x1pcs cable x8pcs (RS-232) x1pcs x16pcs x2pcs...
- Page 4 ① ② ③ ④ ⑥ ⑦ ⑧ ⑨ ⑤ The indicator will turn blue when the power Power indicator is turned on EDID DIP switch Set output resolution through EDID DIP switch IR out Connect with IR blaster extension cable Reset button Restart the device RJ45 output port...
- Page 5 Reset button Restart the device Choose the audio source (output from the Audio switch S/PDIF port) S/PDIF: from the source device ARC: from the TV (receiver end) RJ45 signal input Connect with Cat6/6A/7 network cables When there is power and no HDMI signal, the Power/Signal indicator indicator will flash, when there is HDMI signal, the indicator will light solid blue...
- Page 6 HDMI OUT HDMI Display HDMI OUT HDMI Display Video Source HDMI OUT HDMI IN HDMI Display Network able HDMI OUT HDMI Display HDMI OUT HDMI Display Power HDMI OUT HDMI Display HDMI Display HDMI OUT HDMI Display HDMI OUT HDMI Display...
- Page 7 Switch Sta tu s EDID In f orm a tion 4K@60Hz 2CH 4K@60Hz 5.1CH 4K@60Hz 7.1CH 4K@60Hz HDR 7.1CH 4K@30Hz 2CH 4K@30Hz 5.1CH 4K@30Hz 7.1CH 4K@30Hz HDR 7.1CH 1080p @60Hz 2CH 1080p @60Hz 5.1CH 1080p @60Hz 7.1CH 1080i@60Hz 2CH 1080i@60Hz 5.1CH 1080i@60Hz 7.1CH 1080p @60Hz HDR 7.1CH Au to...
- Page 8 Control Commands Function Descriptions Turn on the network signal output port(s), choose from “01” to “08” (the network ES XX On【Enter】 ports from left to right are: 01, 02, 03, 04, 05,06,07,08.); “All” means all four ports Turn off the network signal output port(s), choose from “01”...
-
Page 9: Reset【Enter
Control Command Reset【Enter】 Function Description Restart the device Received successfully Reset OK Return Values Receive failed Reset FAIL Control Command Baud 19200【Enter】 Function Description Set the baud rate value: 19200 Received successfully Baud 19200 OK Return Values Receive failed Baud 19200 FAIL... -
Page 10: Specification
Item Specification Transmission protocol ipcolor Distribution mode 1 IN 8 OUT Transmission distance CAT6/6A/7≤70m HDMI signal HDMI 2.0, HDCP 2.2 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 1280x960, 1280x800, 1280x768, HDMI Resolution 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600, 3840x2160@24/25/30/50/60Hz, 4096x2160@24/25Hz Audio formats LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1 Support IR passback function (20KHz~60KHz)
