Page 1: User Guide
HDMISS01 1 x 2 HDMI Scaler/Splitter with Digital Audio Break Out 4K with HDCP 2.2 Support User Guide... -
Page 2: Important Safety Notice
For example a SKY Q set-top-box could provide 4K to a main TV and downscale using the HDMISS01 to 1080p and be connected to an Antiference HDMI modulator. The signal can then be distributed over an RF coax cable network to a number of other TV sets. -
Page 3: Package Contents
• Audio output support up to 7.1 surround • Supports CEC pass-through • Built in EDID management, 2/5.1/7.1 patched EDID. • Built in 5 way joystick for full OSD operation. • Compatible with Antiference HDMI modulators Package Contents X1 HDMISS01 X1 5VDC 1A Power Supply X1 DB9(F)/3.5mm STEREO PHONE JACK... -
Page 4: Panel Layout
Panel Layout 1. PC connection for firmware updates 2. Analogue audio output 3. Digital audio output 4. HDMI input 5. DC power input 6. Status LED panel 7. HDMI output 2 8. HDMI output 1... - Page 5 Applications Application splitting to 1080p TV & 4K TV with digital audio break-out: Application with Antiference HDMI Modulator:...
-
Page 6: Menu Operation
Menu Operation Function Down Left Right Confirm Menu Main Menu Sub Menu Sub Menu Function OUTPUT 1 NORMAL Output video same as input video MODE UPSCALE 1080P upscale to 4K EXIT Exit sub menu OUTPUT 1 NORMAL Output colour sub-sampling same as input SUBSAMPLING 4:4:4 - 4:2:0 4K 4:4:4 converts to 4K 4:2:0... -
Page 7: Led Indicators
Should a firmware update be required, this can be carried out by the user using the 3.5mm stereo jack to RS232 cable. In this case instructions for this process will be provided by the Antiference Technical department. DB9(F)/3.5mm STEREO PHONE JACK RS232 3.5 mm Phone Jack... -
Page 8: Technical Specifications
Up/down scale mode only supports resolution conversion - the frequency will not be changed. When using HDMI 2.0 mode a Premium certified HDMI cable must be used. Technical Specifications ITEM NO HDMISS01 HDMI Input HDMI Type A x 1 HDMI Output HDMI Type A x 2... -
Page 9: Declaration Of Conformity
Declaration of Conformity We, ANTIFERENCE LIMITED herewith declare that the HDMI splitter complies with all es- sential requirements and any other applicable conditions set forth on directive 1999/05/CE. According to the WEEE (Waste Electrical and Electronic Equipment) EU Directive, do not dispose of this product as household waste or commercial waste.
