Swan-K1
快速入门指南
Quick Start Guide
V1.1
V1.1
2022.09
Enterprise

Advertisement

loading
Need help?

Need help?

Do you have a question about the Swan-K1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HEQ Swan-K1

  • Page 1 Swan-K1 Enterprise 快速入门指南 Quick Start Guide V1.1 V1.1 2022.09...
  • Page 2 充电 / Charging the Battery and Remote control 电池充电时,请使用原厂充电器进行充电。 遥控器充电时,请确保遥控器处于关机状态并 且使用原厂充电器进行充电。 Please use the original charger when When charging the remote control, please charging for battery. make sure that the remote control is turned off and charged with the original charger. 安装天线...
  • Page 3 组装飞行器 / Assembling the drone 组装机臂 / Assemble the arms 组装机翼 / Assemble the wings 安装螺旋桨 / Installing the Propellers A- 逆时针拧紧 B- 顺时针拧紧 A-Tighten counterclockwise B-Tighten clockwise Swan-K1 EN 机头方向 黑桨帽 白桨帽 Aircraft head direction White nut propeller Black nut propeller 标记 无标记...
  • Page 4 开启与关闭遥控器,安装飞行器电池 / Turning on / off the remote control,Install the battery 短按再长按 开机 / 关机 Short press firstly and then long press to turn on / turn off 安装电池 / Installing the battery 魔术贴朝内 / Battery Velcro facing inward 贴纸朝上 / Sticker side facing up 遥控器...
  • Page 5 如何控制云台 / How to control the gimbal 云台俯仰控制 Gimbal pitch control dial 云台横滚控制 Gimbal roll control 云台回中 Gimbal return to original position 如何连接 APP / How to connect QGC App 点击图标 Disconnected Click on the icon Plan Takeoff Return WAITING FOR VIDEO...
  • Page 6 Vehicle Setup Disconnected App 设置 Analyze Tools Application Settings Application Settings Plan Takeoff Return WAITING FOR VIDEO Back < Application Settings 点击选择 通讯链接 General SIYI-6801116xxx(Bluetooth Device) Click it to choose Comm Links Comm Links Offline Maps MAVLink Console Help Delete Edit Connect Disconnect...
  • Page 7 起飞前校准 / Pre-flight Calibration 飞行前请校准磁罗盘和空速计。 Please calibrate the airspeed meter and compass before flying. 进入参数设置页面 Parameters Vehicle Setup Disconnected Analyze Tools Application Settings Plan Takeoff Return WAITING FOR VIDEO Back < Vehicle Setup Summary Compass Gyroscope Start the individual calibration steps by clicking one of the Airframe 传感器校准...
  • Page 8 Back < Vehicle Setup Summary Compass Gyroscope Airframe Place you vehicle into of the orientation shown below and hold is still Accelerometer Sensors Level Horizon Radio Airspeed Cancel Flight Modes Orientations Power Motors Rotate Incomplete Incomplete Safety Tuning Camera 按图摆放 Arrange as shown Back <...
  • Page 9 Back < Vehicle Setup Summary Compass Gyroscope Start the individual calibration steps by clicking one of the Airframe buttons to the left. Accelerometer Sensors [ cal] calibration started:2 airspeed Level Horizon [ cal] Ensure sensor is not measuring wind Radio Airspeed Cancel Flight Modes...
  • Page 10 摇杆操控飞行器(美国手)/ Joystick control aircraft(US hand) 美国手旋翼状态 美国手固定翼状态 American hand - Rotor status American hand - Fixed wing status 上升 / 下降 左转 / 右转 向前 / 向后 向左 / 向右 加速 / 减速 无 下降 / 爬升 左横滚 / 右横滚 Up/Down Turn Left/Right Forward/...
  • Page 11 起飞与降落,固定翼 / 旋翼切换(美国手)/ Taking off and landing (US hand) ,Fixed wing/rotor switch 上升 在旋翼状态下,飞行器上升至 30 米以上高度,按 键切换为固 定翼状态。 升高飞行器 水平地面 In rotor status, operate the aircraft to an altitude above 30 Raise the aircraft Level ground meters,then switch to fixed-wing status by pressing 下降...
  • Page 12 摇杆操控飞行器(日本手)/ Controlling the drone( Japanese hand 日本手旋翼状态 日本手固定翼状态 Japanese hand - Rotor status Japanese hand - Fixed wing status 前进 / 后退 左转 / 右转 上升 / 下降 向左 / 向右 下降 / 爬升 无 加速 / 减速 左横滚 / 右横滚 Forward/ Turn Left/Right Up/Down...
  • Page 13 起飞与降落,固定翼 / 旋翼切换(日本手)/ Taking off and landing hand) ,Fixed wing/rotor switch Japanese 上升 在旋翼状态下,飞行器上升至 30 米以上高度,按 键切换为固 定翼状态。 升高飞行器 水平地面 In rotor status, operate the aircraft to an altitude above 30 Raise the aircraft Level ground meters,then switch to fixed-wing status by pressing 下降...
  • Page 14 断开电源 / Disconnecting the power 如何导出照片和视频 / How to export photos and videos 拆下机头左侧的盖板,取下 SD 卡,即可拷贝高清图片和视频。 Remove the cover on the right side of the head unit , as well as remove the SD card, then you could copy high resolution pictures and videos.
  • Page 15 3. The device complies with RF specifications when the device used at 20cm from the body. Hereby, Shenzhen HEQ Intelligent Technology Co. LTD. declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to be used in all EU member states.
