Summary of Contents for HEQ Swan-K1 PRO
- Page 1 Swan-K1 快速入门指南 Quick Start Guide V2.2 2022.01...
- Page 2 充电 / Charging the Battery and Remote control 请用 type-C 数据线连接您的充电头给遥控器充电。 请用充电器给电池充电。 Please connect your charger with a type-C data Please charge the battery with the charger. cable to charge the remote control. 组装飞行器 / Assembling the drone 组装机臂 / Assemble the arm 组装机翼...
- Page 3 安装螺旋桨 / Installing the Propellers A- 逆时针拧紧 B- 顺时针拧紧 A-Tighten counterclockwise B-Tighten clockwise Swan-K1 机头方向 黑桨帽 白桨帽 Aircraft head direction White nut propeller Black nut propeller 标记 无标记 Marked Unmarked 开启与关闭遥控器，安装飞行器电池 / Turning on and Turning off the remote control, Install the battery 长按开机...
- Page 4 遥控器 / Remote Controller 飞行模式切换 Flight mode switch 右摇杆 左摇杆 Right Stick Left Stick 一键返航 固定翼 / 旋翼切换 One-click return home Fixed wing/rotor switch 摇杆操控飞行器 / Controlling the drone 美国手旋翼状态 美国手固定翼状态 American hand - Rotor status American hand - Fixed wing status 上升...
- Page 5 位置模式 / Entering into position mode 在户外空旷环境，遥控器飞行模式切换开关向左拨杆等待飞行器进入位置模式。 In an open outdoor environment, move the flight mode switch to the leftmost and wait for the aircraft to enter the position mode. 定高模式 定高模式 位置模式 往左拨杆 Altitude mode Altitude mode Position mode Switch it to the leftmost 起飞前校准...
- Page 6 如何解锁（美国手）/ How to unlock(US hand) 进入位置模式后，油门杆最低，航向杆最右解锁飞行器。电机转动后，请马上松开摇杆。 After entering the position mode, the throttle stick is the lowest and the heading stick is the rightmost to unlock the aircraft. After the motor rotates, please release the joystick immediately. 100% Position Multirotor Armed Aircraft Connected 0.51 17.4V...
- Page 7 如何上锁（美国手）/ How to lock (US hands) 飞行器降落在平地之后，将油门杆打到最低并保持 3 秒后电机停转。 After the aircraft lands on flat ground, hit the throttle stick to the lowest position and hold it for 3 seconds before the motor stops. 100% Altitude Rotor Locked connected 0.51 17.4V Airspeed0.0m/s Flying speed 0.0m/s Altitude 0.0m/s Home distance 0.0m/s...
- Page 8 100% connected Altitude Rotor Locked 17.4V 0.51 Flight Control General Flight Low Battery Warning When the battery reaches the low bttery alarm,the aircraft will return home.Please do not cancel the return home easily. Otherwise,the aircraft will be unable to return home due to insufficient battery power.
- Page 9 3. The device complies with RF specifications when the device used at 20cm from the body. Hereby, Shenzhen HEQ Intelligent Technology Co. LTD. declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to be used in all EU member states.
