- Page 1 Rumble JetKart® + All-Terrain Hoverboard. A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODELS: JKR2HB-BLK | JKR2HB-OS-BLK Designed in Brooklyn | Made in China...
- Page 3 Jetson's top two riding rules: Be safe. Have fun!
-
Page 5: Table Of Contents
Table of Contents Safety Warnings .......................4 What’s in the Box ......................6 Specs &... -
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Before each cycle of operation, the operator shall perform the preoperation checks specified by the manufacturer: That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;... - Page 7 For more information go to www.p65warnings.ca.gov/product MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
-
Page 8: What's In The Box
What’s in the Box 1. SEAT 2. HANDLE (x2, RIGHT AND LEFT) 3. BRACKET (x2) 4. HOVERBOARD 5. JETKART FRAME (X2, FRONT AND REAR) 6. FOOTRESTS (x2) *PRE-ATTACHED TO FRAME 7. FRONT WHEEL *PRE-ATTACHED TO FRAME 8. VELCRO STRAP (x4, INCLUDING 2 SPARE) 9. - Page 9 2 (RIGHT) 2 (LEFT) 3 (RIGHT) 3 (LEFT) 5 (REAR) 5 (FRONT) NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
-
Page 11: Specs & Features
All new Jetson products, excluding parts and accessories, are warranted against defects in materials and workmanship for a period of one year from the date of original retail purchase when used in accordance with Jetson's user manuals (refer to ridejetson.com/support). -
Page 12: Attaching The Handles
1. Getting Started Attaching the Handles • SLIDE A HANDLE ONTO EACH BRACKET BOLT (A) SO THAT THE HANDLE EXTENDS OVER THE END OF THE BRACKET THAT DOES NOT HAVE A NUT. • ON THE SIDE OF THE BRACKET TOWARD WHICH THE HANDLE CURVES, INSERT A MEDIUM BOLT (A) INTO EACH OF THE TWO HOLES AND THROUGH TO THE... - Page 13 TIGHTEN BOLTS USING ALLEN KEY. • REPEAT HANDLE ASSEMBLY ON THE OTHER BRACKET.
-
Page 14: Attaching The Seat
Attaching the Seat BOLT (C) • ALIGN HOLES IN SEAT TO THE FOUR MATCHING HOLES ON WASHER (D) THE SEAT FRAME. • INSERT A SMALL WASHER (D) ONTO EACH SMALL BOLT (C) AND THEN SLIDE A BOLT/WASHER COMBO THROUGH EACH HOLE IN THE TOP OF THE SEAT AND THE FRAME. -
Page 15: Attaching The Brackets
Attaching the Brackets • POSITION THE TWO BRACKETS ON THE SIDE OF THE SEAT SO THAT THE HANDLES ARE POINTING TOWARDS THE FRONT AND BEND OUTWARDS AWAY FROM THE SEAT. • PLACE ONE OF EACH LARGE WASHER (G1 THEN G2) ON THE END OF A LARGE BOLT (F) AND SLIDE THE BOLT/WASHER COMBO THROUGH THE OUTER HOLE OF THE BRACKET. - Page 16 • REPEAT WITH 2ND BRACKET ON THE OTHER SIDE OF THE SEAT. • MAKE SURE THE BRACKETS ARE SECURELY ATTACHED AND THE HANDLES CAN BE MOVED UP AND DOWN EASILY.
-
Page 17: Attaching The Footrest
Attaching the Footrest • SLIDE THE FRONT OF THE JETKART FRAME (WITH THE FOOTRESTS AND WHEEL) INTO THE REAR OF THE FRAME (WITH THE SEAT AND HANDLES.) • SET THE DISTANCE BETWEEN THE SEAT AND THE FOOTRESTS SO THAT THE RIDER'S FEET REST COMFORTABLY ON THE FOOTRESTS KNOB (H) WHEN SEATED AND THE KNEES HAVE A... - Page 18 TWIST TO TIGHTEN KNOB.
-
Page 19: Attaching The Hoverboard
Attaching the Hoverboard • USING THE WRENCH, LOOSEN THE NUT FROM THE BOLT ON EACH BRACKET AT THE BACK OF THE FRAME. ADJUSTABLE BRACKET BOLT... - Page 20 • MAKE SURE THE HOVERBOARD IS TURNED OFF DURING THE ATTACHMENT OF THE JETKART. • POSITION THE HOVERBOARD UNDER THE SEAT SO THAT THE CHARGING PORT ON THE HOVERBOARD IS FACING OUTWARDS FROM THE REAR OF THE JETKART. • IF NECESSARY, ADJUST THE SIZE OF BRACKETS TO THE WIDTH OF THE HOVERBOARD SO THAT THE BRACKETS HUG THE FRONT AND THE BACK OF THE HOVERBOARD.
- Page 21 • OPEN THE VELCRO STRAPS. WRAP THE STRAPS UNDER THE HOVERBOARD WITH THE VELCRO FACING OUTWARD, AND INSERT THE ENDS OF THE STRAPS THROUGH THE SLOTS IN THE FRONT AND REAR OF THE BRACKETS. • PULL THE VELCRO STRAPS TIGHT AROUND THE HOVERBOARD.
- Page 22 • MAKE SURE JETKART IS SECURED TO THE HOVERBOARD.
-
Page 23: Charging The Hoverboard
Charging the Hoverboard • ONLY USE THE INCLUDED CHARGER. • PLUG THE CHARGER INTO THE WALL OUTLET BEFORE THE CHARGING PORT. • DO NOT TURN ON THE HOVERBOARD WHILE IT IS CHARGING. • CHARGE THE BATTERY UNTIL IT IS FULLY CHARGED—UP TO 5 HOURS. •... -
Page 24: Understanding The Indicator Lights
Understanding the Indicator Lights BATTERY INDICATOR LIGHTS STATUS LIGHTS BATTERY INDICATOR LIGHTS STATUS LIGHTS RECALIBRATE YOUR STATUS YOUR HOVERBOARD IS ALL SET. HOVERBOARD. (SEE PAGE 24 OF THIS MANUAL.) ALWAYS CHARGE BATTERY TO 100%—UP TO 5 HOURS. -
Page 25: Low Battery Alerts
Low Battery Alerts WHEN THE HOVERBOARD BATTERY CHARGE NEARS DEPLETION, THE HOVERBOARD WILL ALERT YOU AS FOLLOWS: • BELOW 9% CHARGE - ONLY ONE BATTERY INDICATOR LIGHT WILL ILLUMINATE AND IT WILL BLINK CONTINUOUSLY AND MAKE A LONG BEEPING SOUND IN 2 SECOND INTERVALS. •... -
Page 26: Recalibrating The Hoverboard
Recalibrating the Hoverboard 1.10 YOUR HOVERBOARD'S INTERNAL BALANCE MECHANISMS SOMETIMES NEED TO BE RESET, OR "RECALIBRATED." HOLD POWER BUTTON FOR 5 SECONDS IF YOUR HOVERBOARD STARTS BEEPING, SPINNING, OR HAS RED STATUS INDICATOR LIGHTS, FOLLOW THESE RECALIBRATION STEPS. 1. POWER OFF THE HOVERBOARD AND PLACE IT ON A FLAT SURFACE. ROTATE THE FOOT PADS SO THAT THEY ARE PARALLEL TO THE GROUND AND ALIGNED WITH EACH OTHER. -
Page 27: Getting On The Rumble
2. Making Moves Getting on the Rumble • PLACE THE RUMBLE ON A FLAT SURFACE WITH THE HOVERBOARD TURNED OFF. • CAREFULLY SIT ON RUMBLE, PLACING YOUR FEET ON THE FOOTRESTS. • MAKE SURE THE HOVERBOARD IS LEVELED. • TURN ON THE HOVERBOARD. IMPORTANT: DO NOT TURN THE HOVERBOARD ON BEFORE YOU SIT DOWN. -
Page 28: Helmet Safety
Helmet Safety PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS. -
Page 29: Riding The Rumble
Riding the Rumble. IMPORTANT: ALWAYS CHECK THAT ALL BOLTS, THE KNOB, AND NUTS ARE TIGHTENED BEFORE EACH RIDE. TO GO FORWARD - PUSH DOWN BOTH HANDLES. TO BRAKE/REVERSE - PULL UP BOTH HANDLES. TO TURN RIGHT – PUSH DOWN LEFT HANDLE TO TURN LEFT –... -
Page 30: Riding The Hoverboard On Its Own
Riding the Hoverboard on its Own • TO RIDE STRAIGHT FORWARD, APPLY EQUAL PRESSURE TO THE FRONT OF EACH FOOT PAD. • TO RIDE BACKWARDS, APPLY EQUAL PRESSURE TO THE BACK OF EACH FOOT PAD. - Page 31 • TO TURN LEFT, ROTATE YOUR HIPS SLIGHTLY TO THE LEFT, WHICH WILL ADJUST THE DISTRIBUTION OF PRESSURE ON THE FOOTPADS AND MOVE THE RIGHT WHEEL AROUND FASTER THAN THE LEFT, AFFECTING A LEFT TURN.
- Page 32 • TO TURN RIGHT, ROTATE YOUR HIPS SLIGHTLY TO THE RIGHT, WHICH WILL ADJUST THE DISTRIBUTION OF PRESSURE ON THE FOOTPADS AND MOVE THE LEFT WHEEL AROUND FASTER THAN THE RIGHT, AFFECTING A RIGHT TURN.
-
Page 33: Care & Maintenance
• DO NOT APPLY WATER DIRECTLY TO THE HOVERBOARD, AS THE ELECTRICAL AND ELECTRONIC SYSTEMS MAY GET WET, WHICH COULD RESULT IN A MALFUNCTION OF THE HOVERBOARD THAT COULD LEAD TO PERSONAL INJURY. • IF THE ELECTRIC PARTS OR BATTERY GET WET, DO NOT POWER ON THE HOVERBOARD. CONTACT THE JETSON CARE TEAM FOR ASSISTANCE. - Page 34 Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
- Page 36 US/CANADA: 1-888-976-9904 MEX: +001 888 976 9904 UK: +44 (0)33 0838 2551 Manufactured in Shenzhen, China Imported by Jetson Electric Bikes LLC. P.O. Box 320149, 775 4th Ave #2, Brooklyn, NY 11232 www.ridejetson.com Made in China...
