- Page 1 Y1164A Rack Mount Kit For the M9384B VXG This manual provides documentation for installing the M9384B into an instrument rack using the Y1164A rack mount kit. INSTALLATION GUIDE...
-
Page 2: Safety Notices
DOCUMENT OR ANY INFORMATION commercial computer software or CONTAINED HEREIN. SHOULD commercial computer software © Keysight Technologies, Inc. 2022 KEYSIGHT AND THE USER HAVE A documentation. No additional SEPARATE WRITTEN AGREEMENT government requirements beyond WITH WARRANTY TERMS those set forth in the EULA shall... - Page 3 Documentation is updated periodically. For the latest information about this product, including instrument software upgrades, application information, and product information, browse to the following URL: https://www.keysight.com/find/m9384b To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL: http://www.keysight.com/find/MyKeysight Information on preventing instrument damage can be found at: http://keysight.com/find/PreventingInstrumentRepair...
- Page 5 Keysight M9384B VXG Rack Mount Kit Installation Guide Y1164A Rack Mount Kit To Be Performed By: (X) Keysight Service Center (X) Personnel Qualified by Keysight (X) Customer Estimated Installation Time: 1.0 Hour This rack mount kit provides all parts and documentation required to install the M9384B into a standard Keysight rack.
-
Page 6: Tools Required
Overview Figure 2 Y1164A Rack Mount Kit Assembled on a M9384B VXG In Figure 2, you can see the entire rack mount kit and how it looks when it is fully assembled and attached to the M9384B VXG. Tools Required —... - Page 7 Width Considerations Figure 3 Instrument Dimensions With the side trim strips and strap handles removed, the instrument has a width of 449.4mm. When the rack mount plates are installed, the width should remain at 449.4mm. The standard instrument rack has an internal rail to rail width of 450.8mm, which only leaves 1.4mm of space to fit the instrument.
- Page 8 Kit Installation and Instrument Mounting Procedure 1. Attach front handles to front mounting brackets using the Phillips-Recess M5X0.8 8mm-LG screws (0515-5827). 2. Mount front handle/bracket assemblies to instrument, using 5 Phillips-Recess M4X0.7 10mm-LG screws (0515-5828) on each side. Figure 4 Steps 1 and 2 3.
- Page 9 5. Install L-bracket to rear mounting bracket using 2 Crest-Cup Pan-HD TCRX-T25 M5X0.8 10mm-LG screws (0515-0386) on each side. Figure 6 Step 5 6. Secure rear bracket assemblies to rack rails.
- Page 10 This information is subject to change without notice. © Keysight Technologies 2022 Edition 1, November 2022 M9384-90017 www.keysight.com...
