- Page 1 Prism All-Terrain Hoverboard. A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODELS: JPRISM-BLK | JPRISM-RED | JPRISM-PUR | JPRISM-BLU Designed in Brooklyn | Made in China...
- Page 3 Jetson's top two riding rules: Be safe. Have fun!
-
Page 5: Table Of Contents
Table of Contents Safety Warnings .......................4 Product Overview ......................6 Specs &... -
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Before each cycle of operation, the operator shall perform the preoperation checks specified by the manufacturer: That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;... - Page 7 For more information go to www.p65warnings.ca.gov/product MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
-
Page 8: Product Overview
Product Overview 1. POWER BUTTON 2. CHARGING PORT 3. CHARGER FRONT VIEW REAR VIEW NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT. -
Page 9: Specs & Features
Specs & Features • WEIGHT LIMIT: 220 LBS • PRODUCT WEIGHT: 12 LBS • RECOMMENDED AGE: 12+ • TIRES: 6.5” ALL-TERRAIN • MAX SPEED: 7 MPH • MAX RANGE: 5 MILES • BATTERY: 36V, 2.0AH LITHIUM-ION • MOTOR: 300W, DUAL-HUB •... -
Page 10: Charging The Battery
1. Getting Started Charging the Battery • ONLY USE THE INCLUDED CHARGER. • PLUG THE CHARGER INTO THE WALL BEFORE THE CHARGING PORT. • DO NOT TURN ON THE PRISM WHILE IT IS CHARGING. • CHARGE THE BATTERY UNTIL IT IS FULLY CHARGED - UP TO 5 HOURS. •... -
Page 11: Understanding The Indicator Lights
Understanding the Indicator Lights BATTERY INDICATOR LIGHTS STATUS LIGHTS BATTERY INDICATOR LIGHTS BATTERY 10% - 29% 30% - 74% 75% - 100% PERCENTAGE STATUS LIGHTS RECALIBRATE YOUR PRISM. STATUS YOUR PRISM IS ALL SET. (SEE PAGE 11 OF THIS MANUAL.) IMPORTANT: ALWAYS CHARGE BATTERY TO 100%—UP TO 5 HOURS. -
Page 12: Low Battery Alerts
Low Battery Alerts WHEN THE HOVERBOARD BATTERY CHARGE NEARS DEPLETION, THE HOVERBOARD WILL ALERT YOU AS FOLLOWS: • BELOW 9% CHARGE - ONLY ONE BATTERY INDICATOR LIGHT WILL ILLUMINATE AND IT WILL BLINK CONTINUOUSLY WITH A LONG BEEPING SOUND IN 2 SECOND INTERVALS. •... -
Page 13: Recalibrating
Recalibrating SOMETIMES THE INTERNAL BALANCE MECHANISM OF YOUR HOVERBOARD NEEDS TO BE RESET. THIS PROCESS IS CALLED "RECALIBRATING." HOLD POWER BUTTON FOR 5 SECONDS HOW TO RECALIBRATE: 1. TURN THE PRISM OFF AND PLACE IT ON A FLAT SURFACE. ROTATE THE FOOT PADS UNTIL THEY ARE EVENLY ALIGNED AND PARALLEL TO THE GROUND. -
Page 14: Riding The Hoverboard
2. Making Moves Riding the Hoverboard TO MOVE FORWARD, APPLY EQUAL PRESSURE TO THE FRONT OF EACH FOOTBED. TO MOVE BACKWARDS, APPLY PRESSURE TO THE BACK OF EACH FOOTBED. - Page 15 TO TURN LEFT, APPLY EXTRA PRESSURE TO THE FRONT OF THE LEFT FOOTBED WITH THE FRONT OF YOUR LEFT FOOT.
- Page 16 TO TURN RIGHT, APPLY EXTRA PRESSURE TO THE FRONT OF THE RIGHT FOOTBED WITH THE FRONT OF YOUR RIGHT FOOT.
-
Page 17: Helmet Safety
Helmet Safety PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS. -
Page 18: Care & Maintenance
• AVOID INTENSE PHYSICAL IMPACT AND/OR SEVERE VIBRATION. • PROTECT FROM WATER OR MOISTURE. • DO NOT DISASSEMBLE THE PRISM OR ITS BATTERY. • CONTACT THE JETSON CARE TEAM IF THERE ARE ANY ISSUES WITH THE BATTERY. STORING THE PRISM • FULLY CHARGE THE BATTERY BEFORE STORING. - Page 19 Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
- Page 20 US/CANADA: 1-888-976-9904 MEX: +001 888 976 9904 UK: +44 (0)33 0838 2551 Manufactured in Yueyang, China Imported by Jetson Electric Bikes LLC. P.O. Box 320149, 775 4th Ave #2, Brooklyn, NY 11232 www.ridejetson.com Made in China Date Code: 06/2022...
