Terminal Description - Procom DGC-7RR Operating Instructions Manual

a) Only one temperature measurement out of Room and Canopy can selected at a time
b)
Out of BTS Voltage, Room/Canopy Temperature and Current only 2 parameters can be selected
at the same time.
c)
Single Phase unit can have provision for KW, PF and KWhr

15.0 Terminal description

Terminal Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22,23
24,25
26,27
28
29
30
31
32
33
34
35
36
37
38
15.1 Table A
Parameters in models
Basic Model
Current
BTS Voltage
Room Temperature
Canopy Temperature
BTS Vol + Room/Canopy Temperature
BTS Vol + Current
Cat_DGC-7R-04-08-VERB1-0.doc
Description
Mains R Phase Voltage
Mains Y Phase Voltage
Mains B Phase Voltage
Mains Neutral
Generator Voltage
Generator Neutral
These connections depend upon the models. Please see Table A in
15.1 for details.
Remote
Engine Running( Started)
HWT Sensor
Fuel Sensor
Canopy Temperature
Emergency
LLOP Sensor
V-Belt
External Over Current digital Input
Auxiliary supply +ve
Auxiliary supply -ve
Mains Circuit Breaker
Generator Circuit Breaker
Crank
Hooter
Common for hooter and fuel
Fuel
ANN1 or Choke
ANN2 (Optional)
Common for ANN1 & ANN2
ANN3
ANN4
ANN5
ANN6
Common for ANN3 – ANN6
DGC-7R Digital Genset Controller
Pin 7 Pin8 Pin9
-- -- --
CT+ CT- --
-- -- BTS+
Temp+ Temp- --
Temp+ Temp- --
Temp+ Temp- BTS+
CT+ CT- BTS+
Pin10
--
--
BTS-
--
--
BTS-
BTS-
