- Page 1 Owner’s Manual Taylex Advanced Blower System TAYLEX.COM.AU...
- Page 2 Wastewater Recycling Systems for Australian & New Zealand homes that protect your family and our environment. Taylex Systems produce the highest quality effluent for the safest and best environmental outcome.
-
Page 3: Table Of Contents
Trust Taylex What is a Wastewater Treatment System How does my Wastewater Treatment System work? What keeps my system healthy? What upsets the balance? Suitable Products Products to avoid Servicing your Wastewater Treatment System Operating Instructions for Eco Controller Help & Troubleshooting... -
Page 4: Trust Taylex
Trust Taylex Welcome to Taylex, an Australian family-owned company founded in 1969. We have 80 plus employees and over 80 trained wastewater specialists who market, install and service our range nationally in Australia and New Zealand. Post installation, we have a network of over 300 trained Service Technicians to provide the ongoing care and maintenance for your system. -
Page 5: What Is A Wastewater Treatment System
(grey water) that is discharged from sinks, washing machines, dishwashers, showers, and baths. Your Taylex ABS treats wastewater in an environmentally sustainable way by making use of the naturally occurring bacteria that are present in the wastewater. -
Page 6: How Does My Wastewater Treatment System Work
System, this is where the journey would end and effluent would now be pumped onto your property and into our environment, relying on sand or soil to do the rest. With a Taylex Wastewater Treatment System, there are still four more steps to produce clean, clear, safe water for your yard. If you have an ABS-NR there is an additional Bio Block in this chamber, that encourages further separation of solids. - Page 7 Step Four Step four is in the ‘Clarification Chamber’. More settling occurs here. Once settled to the bottom, this potent mix of Aerobic bacteria and fine particle solids are recirculated to the Primary Chamber to keep it healthy and working hard (not smelly). Step Five The final step in the treatment process is the ‘Disinfection Chamber’.
-
Page 8: What Keeps My System Healthy
Regular Servicing For the Taylex system to work to the best of it’s ability, it needs to be serviced every 3 months. Not only is this regulation, it guarantees your system is getting the adequate care it needs. -
Page 9: What Upsets The Balance
What upsets the balance in my system? The greatest cause of problems for Wastewater Treatment Systems are harmful cleaning products and the washing machine. When using household cleaning products, please remember to: Adhere to the cleaning product manufacturer’s recommended measured dosage. Do not free pour. Use cleaning products that are bio-degradable, low phosphorus and labelled ‘Safe for onsite treatment systems’. -
Page 10: Suitable Products
Suitable Products Dishwashing Liquids As a rule of thumb, it is always recommended to go for dishwashing liquids labeled as ‘Environmentally Friendly’ or ‘Green’. In general, products that are non-toxic, non-chlorine based, and biodegradable are considered safe. Surface Cleaners Similar to above, it’s suggested to look for environmentally friendly products. It is also important to look out for products which are non-antibacterial or harsh chemically. - Page 11 If your technician notices there is a problem, they may recommend that you limit the use of specific products (even if it is listed here as suitable). Taylex promotes the use of low phosphorus, phosphorus free, low sodium & low sulphur products. This practice will reduce the phosphorus levels released to the environment and prolong the life of your phosphorus removal filter (if fitted).
-
Page 12: Products To Avoid
Products to Avoid Strong Antibacterials Cleaning products which contain any of the following should only be used in small doses in your Taylex System; bleaches, disinfectants, whiteners, chlorine, anti-bacterials (Natural anti-bacterials such as Eucalyptus and Tea- tree oils included). Caustic Oven or Drain Cleaners Drain cleaners can do more harm then good for your system. -
Page 13: Servicing Your Wastewater Treatment System
Servicing your Wastewater Treatment System Taylex treatment systems are required to be serviced quarterly and may only be serviced by licensed wastewater service personnel. Not only is it a council requirement, Taylex servicing will also: Ensure that all council Offer an extended warranty... -
Page 14: Operating Instructions For Eco Controller
Operating Instructions - ABS Eco Controller Introduction The Taylex ABS Eco Controller has a number of features that are explained in this section. The Eco Control Panel monitors and controls the Treatment System’s air blower, pump and registers an alarm when it detects a fault in the system. - Page 15 Flashing -Fault detected Press to mute alarm for 24 hours. Solid green -Power is on...
- Page 16 The Power Supply The power outlets for the ECO Controller for your system are located inside the Blower Box. Each switch must be in the ON position at all times. If any or all switches are OFF, the treatment process and alarms may not function. The single GPO is for the 240V –...
-
Page 17: Help & Troubleshooting
ALARM event and discuss it with your Service Agent. If the system goes back into ALARM mode, call your Service Agent. Limit your water usage until the fault is rectified. Contact your local wastewater specialist. taylex.com.au 1300 TAYLEX... -
Page 18: Alarm Codes (Trouble Shooting)
Alarm Codes (Trouble Shooting) Alarm Meaning Action 1 Flash Normal Operation None required 3 Flashes The water level is high Please see below 5 Flashes There is no airflow Call your Service Agent 3 & 5 Flashes Tripped Circuit Breaker Reset Breaker or call your Service Agent 3 Flashes - High Water Alarm A high water level may be self-correcting. - Page 19 3 & 5 Flashes - Tripped Circuit Breaker When your alarm has 3 and 5 flashes, this means you have a tripped circuit breaker. This can be caused by issues with the aerator or other electrical components. If this happens refer to the diagram on page 13 and reset the breaker.
-
Page 20: Warranty
OBSERVED: DO NOT use system or allow wastewater to enter tanks before power services are available to the System and a Taylex Authorised Distributor has been no- tified of pending occupancy of the property and has subsequently commis- sioned (activated) the system. -
Page 21: Rcm Compliance Certificate
RCM Compliance Certificate Certificate No.: 20/RCM/13 Date of Issue: 31 July 2020 Certificate Holder: Taylex Industries Pty Ltd Address: 56 Prairie Road, Ormeau, QLD 4208 Equipment: Controller for waste water treatment tank Brands: “Taylex” Model No’s: ABS Controller; and ABS ECO Controller... - Page 24 Your local distributor: www.taylex.com.au 1300 TAYLEX Owner’s Manual for the Advanced Blower System Taylex Australia Pty Ltd.
