Summary of Contents for Taylex ABS4200

  • Page 1 Installation Manual ADVANCED BLOWER SYSTEM 4200 ABS4200 Standard...
  • Page 2: Table Of Contents

    ELECTRICAL CONNECTION ......................8 COMMISSIONING ..........................8 10. EXCAVATION & LIFTING INSTRUCTIONS ..................9 a. ABS4200 Excavation Instructions ............. 9 b. ABS4200 Lifting Instructions ..............10 11. ELECTRICAL CONNECTION DIAGRAM ....................11-12 Note: Do not act solely on the basis of the material contained in this document. Items herein are general comments only and do not convey advice per say.
  • Page 3: Introduction

    This manual has been put together to explain the installation process of the ABS4200 system as a guide only. Some sites may differ in access and slope, which need to be taken into account when delivering and installing the system.
  • Page 4: Standards & Licencing

    ABS4200 as well as the required local authority approval. If not, it is advised to delay the installation until the plans have been received.
  • Page 5: Delivery And Placement

    Such vehicles will back up to the hole, lift and slew the tank into position behind the vehicle before placing it into the prepared hole. Maximum reach from the rear of the truck to the centre of ABS4200 will vary depending on the size of the crane.
  • Page 6 Page 6 of 13...
  • Page 7: Installation

    2700 1950 3000 2700 * Refer to Excavation & Lifting Instructions on Pages 9 & 10 STANDARD Taylex ABS4200 Top of tank to be a minimum of 100mm above landscaped ground level NON TRAFFICABLE LOADS ONLY NON TRAFFICABLE LOADS ONLY...
  • Page 8  Ensure that the excavated ground or base material is capable of carrying loads of approximately 8 tonne.  The ABS4200 must be level in both inflow/outflow direction and 90° to the inflow/outflow direction (<1° deviation).  Backfilling - Use sand or excavated material/spoil with maximum particle size of 300mm.
  • Page 9: Electrical Connection

    IMPORTANT: The Taylex ABS4200 System cannot be commissioned unless power is connected to the system. The ABS4200 will then be switched on (commissioned) by an Employee of Taylex Australia, a Taylex Accredited Distributor (TAD) or a Taylex Accredited Service Technician (TASA).
  • Page 10 USE ONLY CERTIFIED LIFTING BARS 1. Always use a Spreader Bar and ensure it is certified 2.Lower chains through TOP lifting holes provided in the lid of the ABS4200 3.Loop chains through the lifting holes directly below on the inside wall of the ABS4200...
  • Page 11: Abs4200 Excavation Instructions

    5. Backfill with soil from Excavation in no more than 500mm equally distributed layers around the tank. Avoid backfilling with rocks 2. Ensure drainage has a 1/60 fall to the inlet of ABS4200. Risers over 300mm. are available if the tank needs to be installed deeper in the ground to maintain fall 6.
  • Page 13 Tank 2...
