lap 50697 Installation And Safety Instructions

These instructions are for your safety. Please read through them thoroughly

Parts and Fittings Supplied

Parts and Fittings Supplied
Ref Description
A Plug
Transformer
B LED Light
with 5m cable

Tools Required (not supplied)

Power Drill
12mm hole saw or Forstner bit
Pencil

Before You Start

• Decide on an appropriate location for your product (see siting instructions below).
• If you are in any doubt about installing this product, consult a

Information

This system operates at Safety Extra Low Voltage (12V). It must not be earthed
Never connect the light
Always unplug from the mains when installing or maintaining this system.

Siting Instructions

1. This product is designed for recess mounting in / under kitchen cupboards, bookshelves,
cabinets etc. It requires holes to be drilled into / through the mounting surface.
2.
The chosen location should allow for the product to be securely mounted and safely
connected to the mains supply (240V wall socket or fused outlet socket).
3.
Ensure cables are routed to avoid accidental damage or hazard.
4.
This kit is suitable for indoor use only, but the LED units and connector box are rated at
IP44 making them ideal for use in kitchens and bathrooms. If installing in a bathroom,
the plug transformer must be installed outside a bathroom.
21.11.13
Installation and Safety Instructions
15mm LED Recessed 10lt kit
Type: 50697 (14396) / Type: 39935 (79756)
before use and retain for future reference.
Illustration
directly to the mains without using this plug transformer.
Qty Ref Description
1 C 5m Connecting
Lead
Connector
10 D Connecting
Box
Box
Illustration Qty
1
1
electrician.
Page 1 of 2
