lap 930PG Instruction Leaflet

PIR Adjustment
The unit must be installed in a vertical position, and fitted
1.2m above the ground. The PIR sensor can be adjusted
using the SENS and TIME dials.
The detection angle is set at 105 degrees. The maximum
detection distance is 9m.
Max.8M
Fitting/replacing bulbs
• Fitting/Replacing the bulbs - 1 x MAX 60W E27 GLS
or energy saving equivalent.
Cleaning
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice. The packaging on this product can also be recycled.
Safety information
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
The glass shade must be replaced if it becomes cracked or damaged.
Do not use product without glass shade attached.
UK Manufacturer:
Kingfisher International Products Limited,
3 Sheldon Square, London, W2 6PX,
United Kingdom.
The length of time that the light is on can be adjusted
by turning the 'Time' dial, which can be altered between
8 seconds to 9 minutes duration. See (1) below.
Adjust the light level that the lamp switches on by
adjusting the 'LUX' screw (2).
T
9min
2000lux
8sec
• Always allow the bulb to cool before touching.
Fit the recommended bulbs. Do not exceed the
recommended wattage or use a different shape of
bulb as this may cause your light fitting to overheat.
Plastic parts – Wipe clean with a damp cloth. Do not use
abrasive materials as these will damage the finish.
Do not clean the units with a pressure washer.
Replace Cracked
Shade
EU Manufacturer:
Kingfisher International Products B.V.
Rapenburgerstraat 175E,
1011 VM Amsterdam, The Netherlands.
1 9
Instruction leaflet
Shutter PIR
Outdoor Wall Light
930PG
LUX
2lux
27/05/2021
