UX-CC500
MODEL
F R O M S H A R P M I N D S
Sharp
To ensure Sharp
For your convenience, Genuine Sharp Supplies, Accessories, and
quality, look for
additional Sharp Products can be purchased from the Authorized Sharp
the Sharp Genuine
Reseller where you purchased your product or on-line at:
Supplies Logo on
Your business
products. We
provide a full line
of supplies that
are designed and
tested to maximize
the life and
performance of all
C
2002 Sharp Electronics Corporation
Sharp products.
Design and specifications are subject to change without notice.
C O M E S H A R P P R O D U C T S
TM
Place
congratulations
on the purchase of your new Sharp Product!
w w w . S h a r p P l a c e . c o m
visit SharpPlace
to enter periodic contests and drawings!
Advertisement
Related Manuals for Sharp UX-CC500
Summary of Contents for Sharp UX-CC500
- Page 1 6. Making Copies To ensure Sharp For your convenience, Genuine Sharp Supplies, Accessories, and quality, look for additional Sharp Products can be purchased from the Authorized Sharp the Sharp Genuine 7. Special Functions Reseller where you purchased your product or on-line at: Supplies Logo on w w w .
- Page 2 (3) Telephone number of either the sending machine, business, business entity or individual. In order to program this information into your facsimile machine, please refer to the appropriate instructions in the operation manual." As an NERGY partner, SHARP has determined that this product meets the NERGY guidelines for energy efficiency.
- Page 3 Automatic document feeder 10 pages max. (letter/A4, 20 lb paper) Recording system Thermal transfer recording Display 16-digit LCD display *Based on Sharp Standard No. 1 Chart at standard resolution in Sharp special mode, excluding time for protocol signals (i.e., ITU-T phase C time only).
- Page 4 Halftone (grayscale) 64 levels Compression scheme MR, MH, MMR Applicable telephone line Public switched telephone network Paper tray capacity Letter: Approx. 50 sheets (20-lb. copier paper at room temperature; maximum stack height should not be higher than the line on the tray) Legal: 5 sheets Recommended paper weight: 20-lb.
- Page 5 Accessory cordless handset UX-K01 (up to 3 handsets can be added) As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.
- Page 6 - The machine produces odors, smoke, or unusual noises. - The power cord is frayed or damaged. - The machine has been dropped or the housing damaged. Do not allow anything to rest on the power cord, and do not install the machine where people may walk on the power cord.
- Page 7 Table of Contents A Look at the Operation Panel 1. Installation Unpacking Checklist ........12 Setting Up.
- Page 8 Table of Contents Sending a Fax by Automatic Dialing ......74 Sending a Fax From Memory ......81 5.
- Page 9 A Look at the Operation Panel Fax machine REC/ PLAY MEMO INTERCOM PQRS WXYZ REDIAL RESOLUTION/ RECEPTION MODE STOP COPY/HELP START/MEMORY FUNCTION SPEAKER DELETE REPEAT SKIP Display This displays messages and prompts to help you operate the machine. INTERCOM key Press this key to page or locate the cordless handset.
- Page 10 STOP key Press this key to cancel an operation before it is completed. COPY/HELP key When a document is in the feeder, press this key to make a copy of a document. At any other time, press this key to print out the Help List, a quick reference guide to the operation of your fax machine.
- Page 11 Cordless handset FUNCTION REMOTE /PAUSE /FLASH START REVIEW SEARCH TALK DOWN RECEPTION PQRS WXYZ PLAY PLAY NEW STOP REPEAT SKIP DELETE REDIAL INTER HOLD ERASE Antenna Display This displays messages and prompts to help you use the cordless handset. UP and DOWN arrow keys Receiver volume: When talking on the cordless handset, press these keys to adjust the receiver volume.
- Page 12 TALK key Press this key to make or answer a call. REVIEW (left) arrow key Press the REVIEW arrow key and then the UP or DOWN arrow key to scroll through your 30 most recent calls (only available if you have Caller ID). This key can also be used to move the cursor left when entering or editing an auto- dial number or name.
- Page 13 RECEPTION key REMOTE /FLASH Press this key after pressing to change the reception mode on the fax machine. STOP key Press this key to stop playback of messages. DELETE Press this key while listening to a message to delete it. To delete all your messages, press this key after playback ends (while the display shows REMOTE MODE), followed by START...
- Page 14 1. Installation Unpacking Checklist Before setting up, make sure you If any are missing, have all of the contact your following items. dealer or retailer. Paper tray Paper tray Operation Gears (2) extension manual Handset Handset Telephone Imaging film cord line cord (initial starter roll) Cordless...
- Page 15 Setting Up Setting Up Selecting a location for the fax machine To maximize the talking range of the cordless handset, we recommend installing the fax machine in a high and central location away from obstructions such as walls. High and central location with no obstructions Keep the fax machine away...
- Page 16 Setting Up Connecting the handset Connect the handset as shown and place it on the handset rest. ♦ The ends of the handset cord are identical, so they will go into either jack. Make sure the handset cord goes into the jack marked with a handset symbol on the side of the machine!
- Page 17 Setting Up Connecting the telephone line cord Insert one end of the line cord into the jack on the back of the machine marked TEL. LINE. Insert the other end into a standard (RJ11C) single-line wall telephone jack. Setting the dial mode The fax machine is set for tone dialing.
- Page 18 Setting Up Note: If your area experiences a high incidence of lightning or power surges, we recommend that you install surge protectors for the power and telephone lines. Surge protectors can be purchased at most telephone specialty stores. About condensation If the machine is moved from a cold to a warm place, it is possible that condensation may form on the scanning glass, preventing proper scanning of documents for transmission.
- Page 19 Setting Up Raising the base antenna Raise the base antenna to ensure clear communication with the cordless handset. Connecting the cordless handset charger Connect the AC adapter to the cordless handset charger. Fit the cord into the holders. Plug the AC adapter into a standard 120 V AC outlet.
- Page 20 Setting Up Installing the battery and charging the cordless handset Connect the battery connector Connect the battery connector , and then place the battery pack in the cordless handset. • Place the wires as shown. Black Black Place the battery cover on the cordless handset, making sure it snaps firmly into place.
