- Page 1 Last version of this manual IP2395EN • 2022-06-20 Technical manual Ditec DOD Industrial sectional door automations (translation of the original instructions) www.ditecautomations.com...
-
Page 2: Table Of Contents
Ditec DOD14 chain link-up installation ....................12 Assembly of DODT drive shaft with Z24 pinion ....................13 Cord release installation ..........................14 Ditec DOD14 installed on sliding door ....................15 Ditec DOD14 installed on sliding door ....................15 Electrical connections ...........................16 Ditec DOD14 - DOITDD1P electrical connections ....................16 9.1.1... -
Page 3: General Safety Precautions
General safety precautions ATTENTION! Important safety instructions. Follow these instructions carefully. Failing to follow the instructions contained in this manual may result in serious personal injury or damage to the equipment. Keep these instructions for future reference. This manual and the manuals for any accessories can be downloaded at www.ditecautomations.com This installation manual is intended for qualified personnel only •... - Page 4 devices must protect any crushing, shearing, conveyance and danger zones of the motorised door or gate. Apply the markings provided for by the regulations in force to identify danger zones • Each installation must have visible indication of the identification data for the motorised door or gate •...
-
Page 5: Declaration Of Incorporation Of Partly Completed Machinery
SE-261 44 Landskrona Sweden, declare, under our sole responsibility, that the type of equipment with the name: Ditec DOD14/14PS 230 V~ automation for sectional doors Ditec DOITDD1P 230 V~ automation for sectional doors kit complies with the following directives and their amendments: 2006/42/EC Machinery Directive (MD), regarding the following essential health and safety requirements: 1.1.2, 1.1.3, 1.2.1, 1.2.2, 1.2.3, 1.2.4.2, 1.2.6, 1.3.9, 1.4.3, 1.7.2, 1.7.3, 1.7.4, 1.7.4.1, 1.7.4.2. -
Page 6: Declaration Of Conformity
SE-261 44 Landskrona Sweden Declare under our sole responsibility that the types of equipment with names: Ditec DOD14/14PS 230 V~ automation for sectional doors Ditec DOITDD1P 230 V~ automation for sectional doors kit Comply with the following directives and their amendments: •... -
Page 7: Technical Data
The sectional doors can only be manually moved by means of a handle (installing the DODSBV release device) or a chain (installing the DODSBC release device). The given operating and performance features can only be guaranteed with the use of DITEC accessories and safety devices. -
Page 8: Machinery Directive
1.2 Machinery Directive According to the Machinery Directive (2006/42/EC), the installer who motorises a door or gate has the same obligations as the manufacturer of a machine, and as such must: - prepare the technical documentation, which must contain the documents indicated in Annex V of the Machinery Directive;... -
Page 9: Installation Type
3. Installation type Ref. Code Description Cable Actuator (motor) 4 x 1.5 mm² DOD14 Extra low voltage limit switch unit 3 x 0.5 mm² LCA85/LCA85B Control panel 3G x 1.5 mm² Flashing light 230 V 2 x 1mm² FL24 Flashing light 24 V RG-58 coax Antenna (integrated in the flashing light) cable (50 Ω) -
Page 10: Ditec Dod14 Axle Installation
4. Ditec DOD14 axle installation FL24 DOD14 AXK4 AXK5M AXK5I AXK5NM AXK5NI AXR7 LCA85 LCA85B DOD14 SOFAP20 SOF2M20-SOF3M20 SOFA15-SOFA20-SOFA25 Ø WARNING: For correct operation we advise to move the door at a speed lower than 0.2 m/s. Rotating Door cable... -
Page 11: Motor Assembling
4.1 Motor assembling Mount the DOD14 motor onto the wall bracket and release idle bracket as shown in figure. 4.2 Installation - Fit the DOD14 motor onto the drive shaft. - After having determined the position of the wall bracket, drill the holes and secure the bracket in place with dowels (not supplied). -
Page 12: Ditec Dod14 Chain Link-Up Installation
5. Ditec DOD14 chain link-up installation DOD14 ATTENZIONE: corona non di ATTENTION: crown not sup- nostra fornitura plied by us CAT1+ CATG DODT LCA85 LCA85B NOTE: DODT - Drive shaft with Z24 pinion and key Rotating Door cable Door Reduction... -
Page 13: Assembly Of Dodt Drive Shaft With Z24 Pinion
5.1 Assembly of DODT drive shaft with Z24 pinion Fasten the wall fixing brackets and the release idle bracket onto the Ditec DOD14 motor and put the shaft with the pinion into the position required for traction (on one of the two sides of the motor). -
Page 14: Cord Release Installation
6. Cord release installation The cord release on the sectional doors should only be used by skilled per- sonnel, for adjusting the door balancing springs during the installation and maintenance phases. DO NOT USE TO MOVE THE SECTIONAL DOORS MANUALLY. - Fasten the brackets to the gearmotor, then pass the release cord. -
Page 15: Ditec Dod14 Installed On Sliding Door
7. Ditec DOD14 installed on sliding door DODT DODRIN1 DOD14 unlock device OPENING LCA85 LCA85B 3Gx1.5 mm² [DOD14] Rotating Reduction Torque Door speed Max Run Max Force Type Pinion Crown speed ratio [Nm] [m/s] [RPM] DODT DODRIN1 DOD14 0,11 8,35... -
Page 16: Electrical Connections
Make sure there are no sharp edges that may damage the power supply cable. Connection to the mains power supply (in the section outside the automation) is made on an independent channel, separated from the connections to the control and safety devices. 9.1 Ditec DOD14 - DOITDD1P electrical connections Contatto supplementare Additional contact... -
Page 17: Ditec Doitdd1P Wiring Diagram
9.1.1 Ditec DOITDD1P wiring diagram 4G x 1,5 mm² (motor) L= 5,3 m 3 x 0,5 mm² (limit switch) L= 5,3 m LCA85B 230 V~ - 50 / 60 Hz Power supply... -
Page 18: Product Start-Up
9.2 Product start-up ATTENTION: if the control panel is used to replace an identical control panel which is faulty, the last automation configuration can be reset by inserting the old control panel storage module into the new control panel and loading the last set configuration using the menu sequence →... -
Page 19: Limit Switch Adjustment
9.3 Limit switch adjustment With door open, adjust screw [A] so as to cause the associated cam to trigger the opening limit switch. With door closed, adjust screw [C] so as to cause the associated cam to trigger the closing limit switch. -
Page 20: Ditec Dod14Ps Electrical Connections
9.4 Ditec DOD14PS electrical connections With the provided push button the control panel isn’t necessary, the automation works as “hold to run” function. Additional switch Opening limit switch Black Closing limit switch Brown Brake Grey Blue 230 V~ - 50 / 60 Hz... -
Page 21: Routine Maintenance Plan
10. Routine maintenance plan Perform the following operations and checks every 6 months according to intensity of use of the automation. Disconnect the power supply, 230 V~: - Maintenance and lubrication of the mechanical parts must be carried out with the door closed (fully lowered). - Page 22 All the rights concerning this material are the exclusive property of ASSA ABLOY Entrance Systems AB. Although the contents of this publication have been drawn up with the greatest care, ASSA ABLOY Entrance Systems AB cannot be held responsible in any way for any damage caused by mistakes or omissions in this publication. We reserve the right to make changes without prior notice.
