Summary of Contents for TVS ETFI Jupiter

  • Page 2 Customer’s Name And Address ............................................................Frame Number..................................Engine Number................................... Key Number............... Colour..................Date Of Sale................ Registration Number............. Selling Distributor / Dealer’s Address Stamp: ............................................................
  • Page 3 UNIQUE FEATURES OF TVS JUPITER ® ECONOMETER ENGINE Kill SWITCH Y o u r s p e e d o m e t e r h a s 'Engine Kill Switch' is an another ® ECONOMETER which indicates unique feature in scooter which...
  • Page 4 Tubeless tyres reduce the chances premium LED head lamp. Efficient of getting punctured. Even if there is and bright, this gives TVS Jupiter a a puncture, sudden leakage of air is totally upgraded Look and Style with avoided, thereby provide better better visibility for night rides.
  • Page 5 UNIQUE FEATURES OF TVS JUPITER PATENTED E-Z CENTRE STAND S Y N C H R O N I S E D B R A K E TECHNOLOGY (SBT) E-Z Centre Stand of your scooter Synchronised Brake Technology reduces the effort required to place reduces the stopping distance, while the scooter on stand.
  • Page 6 Dealer / Authorised Service Centers. for fixing the socket. Refer page No. 22 for usage details. FRONT GLOVE BOX* TVS Jupiter is provided with glove box front. Which has 1 litre storage capacity and used to hold your mobiles while charging or hold a small bottle.
  • Page 7 Thank you for choosing TVS Jupiter , a stylish scooter with all new CVT-I Engine with Fuel Injection & many class-leading features. As a proud owner of TVS Jupiter , you are now part of a family of millions of satisfied TVS customers.
  • Page 8 This Owner's Manual contains a host of useful information. Please take the time to read this manual before you ride your new TVS Jupiter. Get familiarised with the operation of your scooter for maximum safety and pleasure. The better you know your vehicle, the more pleasure you will experience riding your new vehicle.
  • Page 9 SAFETY INFORMATION Operating this vehicle safely is an important responsibility of the rider. To help you make decisions about safety, we have provided operating procedure and other information in this manual. This information alerts you on potential hazards that could hurt you or others. Since it is not possible to warn you about all hazards associated with operating or maintaining the vehicle, you must use your own judgement.

  • Page 10: Table Of Contents

    CONTENTS Running-in information Safe riding tips Know your TVS Jupiter Riding your TVS Jupiter Maintenance Service record sheet Technical specifications -VIII-...

  • Page 11: Running-In Information

    Timely performance of the first service will ensure optimum service life and performance from the engine. Caution Replacing the engine and transmission oil during first service is most important for better life of engine. Always use TVS TRU4 PREMIUM oil (SAE10W30 API-SL, JASO MA2) for better performance and life.

  • Page 12: Safe Riding Tips

    Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice riding TVS Jupiter in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls. Remember practice makes you perfect.
  • Page 13 SAFE RIDING TIPS Posture Cornering Proper vehicle riding starts with proper posture. When cornering, centrifugal force works in a direction perpendicular to the direction in which the vehicle is 1. Keep your elbows relaxed and flexible. moving. Centrifugal force increases in proportion with 2.
  • Page 14 As the vehicle speed increases, the stopping distance EMISSION CONTROL also increases progressively. Be sure that, you have All the TVS vehicles are tested in the factory for sufficient distance between you and the vehicle or optimum fuel efficiency and CO levels.
  • Page 15 12 months from the date of purchase. Get Crankcase emission control system your vehicle certified by the Government authorised The engine of new TVS Jupiter is equipped with a emission testing station after initial 12 months of closed crankcase system to prevent discharging usage.

  • Page 16: Know Your Tvs Jupiter

    KNOW YOUR TVS JUPITER VEHICLE IDENTIFICATION NUMBER Serial numbers of both frame and engine are required for vehicle identification. They are also required to assist your Dealer for ordering parts or referring to special information. The frame serial number is stamped on the frame, at The engine serial number is stamped on the left side the rear end below the seat assembly.
  • Page 17 KNOW YOUR TVS JUPITER LOCATION OF PARTS - HANDLE BAR 1. Speedometer assembly 2. Rear view mirror L 3. Engine kill switch 4. Right hand brake lever 5. Throttle grip 6. Electric starter switch 7. Ignition cum steering lock 8. Bag hook (front) 9.
  • Page 18 KNOW YOUR TVS JUPITER LOCATION OF PARTS - VEHICLE LEFT SIDE 1. Rear brake adjusting nut 2. Kickstarter lever 3. Effortless easy center stand 4. Pillion foot rest L 5. Reflex reflector 6. Speedometer cable 7. Front brake adjusting nuts...
  • Page 19 KNOW YOUR TVS JUPITER LOCATION OF PARTS - VEHICLE RIGHT SIDE 1. Front wheel axle nut 2. Bag hook (rear) 3. Cover front 4. Pillion foot rest R 5. Gauge oil level 6. Muffler assembly 7. Rear fender 8. Seat assembly...
  • Page 20 KNOW YOUR TVS JUPITER LOCATION OF PARTS - VEHICLE FRONT & REAR FRONT 1. LED Head lamp 2. Head lamp focus adjuster 3. Turn signal lamp front LH 4. Turn signal lamp front RH 5. Throttle cable adjuster REAR 1. Fuel tank cap 2.
  • Page 21 KNOW YOUR TVS JUPITER CONTROL KEY 3. ‘LOCK’ position TVS Jupiter comes with an 'all in one lock'. It has five TVS Jupiter steering can be locked in both 'left' and positions and they are: 'right' directions. 1. ‘OFF’ position To lock the steering, turn the handle bar all the way to the 'left' or 'right'.
  • Page 22 'Click' sound is heard. 4. 'Seat unlock' position SPEEDOMETER ASSEMBLY Seat lock is inbuilt in 'all in one lock' of TVS Jupiter. To open the seat, keep the key in 'OFF' position and turn 1. Speedometer it to anticlockwise direction without pushing the key Indicates vehicle speed in kilometers per hour.
  • Page 23 Power indicator (amber lamp) indicates that the deployed condition the vehicle will not stop. As a safety vehicle is running in power mode which results in measure it is recommended to visit the nearest TVS reduced fuel economy. Motor Company Authorised Distributor or Dealer / Authorised Service Centers.
  • Page 24 LED HEAD LAMP Always use the appropriate turn signal lamps when TVS Jupiter comes with a LED head lamp which glows you intend to change lanes or take turns. Be sure to automatically once the engine is started. The head switch 'OFF' it after negotiating the lanes or turns.
  • Page 25 (or) helps you relax while TVS Jupiter has a combined switch for head lamp waiting in a long traffic signal (or) a slope. 'high / low beam' and 'pass-by'. To operate the pass-...
  • Page 26 KNOW YOUR TVS JUPITER 2. Throttle grip Warning Engine speed is controlled by the rotation of the Use appropriate head lamp beam 'high / low' as per throttle grip. Twist it towards you to increase the the traffic and road conditions for your safety and to engine speed and twist it away from you or release it avoid inconvenience to other riders.
  • Page 27 KNOW YOUR TVS JUPITER FUEL TANK* CAP While refueling, avoid spillage of gasoline on the tyre. If fuel spills on tyre, the tyre will loose its grip on the Fuel tank is located at the rear end of the vehicle road.
  • Page 28 KNOW YOUR TVS JUPITER EFFORTLESS E-Z CENTRE STAND TVS Jupiter is equipped with a effortless centre stand. The centre stand (1) has a pivoted flexible spring loaded lever arm (stand extension) (2) to increase the lever ratio, which enables parking on centre stand effortlessly and very conveniently.
  • Page 29 10x12 mm spanner Combination screw driver bit Screw driver handle Tool bag Warning Operating the TVS Jupiter overloaded will hamper riding stability and may lead to loss of control. Hence, it is advisable to carry the recommended amount of load only. -19-...
  • Page 30 GLOVE BOX FRONT* storage which is useful to store any important articles TVS Jupiter is provided with glove box front. Which separately. Additional lock with key is supplied as an has 1 liter storage capacity and used to hold your optional accessory for this secondary storage.
  • Page 31 KNOW YOUR TVS JUPITER Just pull out the hook from the top (A) to hang your Warning luggage. Push back the hook once it is free. Ensure that your mobile or any material stored is Similarly, the other one is located on the cover front safely held with in the glove box front while riding your below front end of the seat assembly.
  • Page 32 KNOW YOUR TVS JUPITER SMART PHONE CHARGER* 4. Do not charge your mobile when engine is off. This smart phone charging socket enables you to 5. Do not use other device, this port is for charging charge your smart phone when you are traveling.

  • Page 33: Riding Your Tvs Jupiter

    RIDING YOUR TVS JUPITER PRE RIDE INSPECTION Check the following items before riding. ITEM WHAT TO CHECK FOR Engine oil Availability of oil upto the level (page No. 34) Transmission oil Availability of oil upto the level (page No. 35)
  • Page 34 Use only EURO V gasoline with minimum RON 91. 2. As the vehicle picks up speed, increase the throttle slowly. EURO V gasoline containing upto 5% of ethanol by volume can be used. Contact your TVS Motor Caution Company Authorised Distributor or Dealer /...
  • Page 35 RIDING YOUR TVS JUPITER CHECKS AND TIPS FOR IMPROVING FUEL Running with low transmission oil will cause damage ECONOMY to the gears and bearings. Regular checks R e gularly ins pe c t the e ngine oil and the Carry out the periodic maintenance checks as transmission oil for correct level and top-up if specified in this manual (page no.
  • Page 36 It leads clutch shoes wear and wastage of fuel. Note The on-road mileage of TVS Jupiter is dependent on several factors like Road condition, Quality of fuel, Riding speed, operation of Clutch and Brake, Tyre inflation, Maintenance / timely servicing of vehicle, load etc.

  • Page 37: Maintenance

    Cylinder head, steering components, suspension and wheel components etc., are key items and require very special and careful servicing. TVS Motor Company Limited strongly recommends that the jobs as per the maintenance schedule be performed by your TVS Motor Company Authorised Distributor or Dealer / Authorised Service Centers.
  • Page 38 MAINTENANCE PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier) service service Item Service Every Every Remarks 500 - 750 2500 - 3000 5000 - 6000 8500 - 9000 3000 km 6000 km Period from the date of sale 2 months 4 months 8 months 12 months...
  • Page 39 MAINTENANCE service service Item Service Every Every Remarks 500 - 750 2500 - 3000 5000 - 6000 8500 - 9000 3000 km 6000 km Period from the date of sale 2 months 4 months 8 months 12 months 4 months 8 months All control cables I, A &...
  • Page 40 R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; DR - Drain; L - Lubricate; TI - Tighten; S - Set ** Check for abnormal vehicle jerk / noise while opening the cap / leak. If found any, contact TVS Motor Company Authorised Distributor or dealer / Authorised service centers.
  • Page 41 2. Remove the front panel mounting screws (4 voltage is less than 12.4 volts, charge the battery Nos.). using recommended MF battery charger at TVS 4. Remove the bracket license plate mounting Motor Company Authorised Distributor or Dealer / hexagonal bolts (2 Nos.) and take out the bracket Authorised Service Centers.
  • Page 42 (15A x 1 and 10A x 2) located near the battery. lncase of any abnormality or for removal of battery Follow the procedure given below for inspecting and from the vehicle, contact TVS Motor Company replacing the fuse. Authorised Distributor or Dealer / Authorised Service 1.
  • Page 43 Incase the fuse 3. Gently pull out the cover front by dislocating its fails again, consult the nearest TVS Motor lugs. Authorised Distributor or Dealer / Authorised 4. Clean the dust and mud around the spark plug Service Centers.
  • Page 44 MAINTENANCE A spark plug with heavy carbon deposits will not plug by 1/8 of rotation after sealing by using only the produce strong sparks. Hence, only if necessary, hand tool. clean the carbon deposits from the spark plug with a ENGINE OIL LEVEL small wire brush or spark plug cleaning tool.
  • Page 45 MAINTENANCE 5. If the oil is less than the minimum level, add ‘TVS 4. Check for the flow of oil from oil level hole. TRU4 PREMIUM’ oil upto the maximum level 5. If the level is less (if there is no oil flow), top-up mark.
  • Page 46 MAINTENANCE 15 ~ 20 mm 4. After obtaining the necessary free play, inspect for the clearance between the bullet (3) and slot end (4) marked as “S” as shown in the figure. 5. If any clearance is found, turn the adjuster nut (2) at the top side in the slot marked as “S”...
  • Page 47 Braking Technology (SBT) adjust the brakes with additional care. If not it may result in brakes not Caution working properly. Please contact TVS Motor Replace the brake shoes as a set, if the wear limit Company Authorised Distributor or Dealer / indicator shows beyond the wear limit even after indexing the lever.
  • Page 48 MAINTENANCE Warning Check front brake (drum brake type) and rear brake play periodically. However the brake play needs to 10 ~ 15 mm be adjusted more frequently depending upon the usage. Brake shoe wear indicator (Rear brake) When brake is applied, the wear limit indication pointer (1) on the rear brake cam lever should be within the wear limit indicator (2) on the crankcase LH.
  • Page 49 TYRES REAR SHOCK ABSORBERS Tyre pressure TVS Jupiter is provided with 3 step adjustable rear Check the tyre pressure atleast once in a week if not shock absorbers to meet different road and load. more frequently. Insufficient air pressure in the tyres There are 3 notches for adjusting spring load.
  • Page 50 MAINTENANCE Tyre rotation direction Tyre tread condition While reassembling the tyres, after removing from Operating the vehicle with excessively worn tyres will the wheel rim, ensure that the arrow mark facing the decrease riding stability and can lead to loss of control. direction of wheel rotation while fixing the tyre on the It is recommended to replace the tyre when the tyre front wheel rim.
  • Page 51 MAINTENANCE FRONT WHEEL REMOVAL AND REASSEMBLY REAR WHEEL REMOVAL AND REASSEMBLY 1. Place the vehicle on the centre stand. 1. Remove the axle nut (1) along with a washer. 2. Hold the rear brake firmly and remove the wheel 2. Pull out the axle (2) along with a washer and take mounting nut (A) along with a washer.
  • Page 52 Crank the required. engine few times and reinstall the spark plug. 3. Fill the engine oil (TVS TRU4 PREMIUM oil) and 5. Remove the battery, store it away from direct check the oil level using gauge oil level.
  • Page 53 1. Tool kit complete. 12. Any other job as necessary. 2. Recommended spark plug one number. 13. Have your vehicle checked at any TVS Motor 3. Head lamp and turn signal lamp bulb each one. Company Authorised Distributor or Dealer / Authorised Service Centers.

  • Page 54: Service Record Sheet

    SERVICE RECORD SHEET PAY SERVICE RECORD SERVICE RECORD SHEET Sl.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 1st service between (a) 500 - 750 km or (b) 2 months from the date of purchase, whichever of the two occurs earlier.
  • Page 55 SERVICE RECORD SHEET PAY SERVICE RECORD SERVICE RECORD SHEET Sl.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 6th service between (a) 14500 - 15000 km or (b) 20 months from the date of purchase, whichever of the two occurs earlier.

  • Page 56: Technical Specifications

    TECHNICAL SPECIFICATIONS MANUFACTURER : TVS MOTOR COMPANY LIMITED P.B. No 4, Harita, Hosur - 635 109, India. ENGINE TRANSMISSION Type : Single cylinder, 4 stroke, air Clutch : Dry - Centrifugal clutch cooled, spark ignition engine Primary transmission : CVT (Continuous Variomatic Cylinder bore : 53.5 mm...
  • Page 57 TECHNICAL SPECIFICATIONS CHASSIS Spark plug gap : 1.0 ~1.1 mm Dimensions and weight Battery : 12V, 4Ah MF battery Frame : Duplex tubular frame Generator : Fly wheel magneto, 12V, 130W Front suspension : Telescopic hydraulic Head lamp : 9V, 9.5W High beam LED Rear suspension : Toggle link, adjustable rear shock absorber...
  • Page 58 : TVS TRU4 PREMIUM oil 750 ml during regular service and 800 ml incase of disassembly. Transmission oil & capacity : TVS TRU4 PREMIUM oil 100 ml during regular service and 120 ml incase of disassembly. Front fork oil & capacity : Gabriel Premium front fork oil, 84 ±...
  • Page 60 K6210920 - OWNERS MANUAL JUPITER 110 CC EURO - V (EXP)
