NetComm NB702 SHDSL Specifications

Today's SME and Enterprise business users are constantly battling the unrelenting pressure for more in less time.
NetComm's NB702 high speed symmetrical DSL modem router has been designed to utilise existing 2 wire
telephone infrastructure to deliver blistering internet connectivity to performance hungry businesses.
Based upon the international standard for G.SHDSL, the NB702 delivers data transfer rates of up to 2.3Mbps
symmetrically (up and downstream) making the NB702 ideal for applications such as IP Telephony, Web and
Email server hosting, Video Conferencing, large data file transfers or corporate LAN to LAN connections.
Features
High Speed Symmetrical Data Transmission on one Twisted Pair of Copper Wire
ITU standard PAM16 Line Code, complies with G.991.2 and G.994.1 standards
Supports Annex.A and Annex.B mode operation
Support Wetting Current range from 0.3mA to 3mA
One Ethernet switch with four 10/100Mbps auto-sensing ports for PC or LAN connection
Provides a broad range of Symmetrical Multi-rate Data Transmissions from 72 Kbps up to 2.3 Mbps
Supports PPPoE (RFC2516), PPP (RFC2364), and IP (RFC 2225/RFC1577) over ATM over SHDSL
RFC2684 (RFC1483) Bridged/Routed for both LLC/VC MUX
DHCP server supported for easy LAN IP address management
Allows LAN users to access Internet through Network Address Translation (NAT, IP sharing) simultaneously
Local OAM&P through command line interface via RS-232 Craft port
Configuration and management by local Telnet, SNMP, and WEB Browser through the Ethernet interface, and remotely through
SHDSL interface
Firmware upgradeable through TFTP
High performance, simple operation, and low power consumption
NETCOMM LIMITED
ABN 85 002 490 486
Up to 2.3Mbps
Symmetrical data
rates.
Use existing
telephone
Infrastructure.
Bridge or Router
modes.
High Speed Symmetrical Internet Connections
to service your business needs.
• 2-6 Orion Road, LANE COVE, NSW, 2066 • phone 02 9424 2070 • fax 02 9424 2010 • email sales@netcomm.com.au
www.netcomm.com.au
NB702 SHDSL
