- Page 1 NETCOMM LIBERTY™ SERIES ADSL2+ Wireless N Modem Router with VoIP Quick Start Guide NB16WV...
-
Page 2: Hardware Installation
Hardware Installation The router has been designed to be placed on a desktop. All of the cables exit from the rear for better organization. The LED indicator display is visible on the front of the router to provide you with information about network activity and the device status. See below for an explanation of each of the indication lights. - Page 3 FRONT PANEL ICON COLOUR STATE DESCRIPTION Power Blue The NB16 is powered off Flashing The NB16 is currently starting up The NB16 is powered on ADSL Sync Blue A connection via an ADSL service is not currently configured Flashing Connecting to an ADSL service Connected via an ADSL service 3G Signal Blue...
- Page 4 Insert your 3G dongle (with an active SIM card) into the 3G dongle USB slot on the rear of the NB16. Connect the power adapter to the power socket on the back of the NetComm router. Plug the power adapter into the wall socket and switch on the power.
-
Page 5: Ethernet Cable
Connecting to the router via an Ethernet Cable Computer Connect the yellow Ethernet cable provided to one of the yellow LAN ports on the back of the NB16. Connect the other end of the yellow Ethernet cable to your computer or to another Ethernet enabled device like a gaming console, a TV or a home cinema system. -
Page 6: Connecting The Router To The Internet
Enter “admin” into both the username and password fields and click “Login”. The “First-Time Setup Wizard” should then be displayed. Click on the “Yes, Let’s get started with the wizard” button to configure your NetComm Router. Select your chosen connection type. You can select from:... - Page 7 Telephone Exchange ADSL: Select the ADSL connection type and enter the username/password as supplied by your ADSL provider Please note: To enable a backup connection via 3G, tick the checkbox and then enter the appropriate 3G connection information. This information should be supplied by your 3G provider. You will also need to enter a high availability website (e.g.
- Page 8 “Back” until you reach the required page and adjust your settings accordingly. Click “Next” until you reach the summary page again. The NetComm Router will now attempt to connect using the details you have entered. This can take up to 2 minutes.
- Page 9 Connecting to the Router via Wireless (WiFi) Ensure WiFi is enabled on your device (computer/laptop/smart phone/gaming console). Scan for wireless networks in your area and connect to the network name that matches the Wireless network name found on the Wireless Security Card (included in the box). When prompted for your wireless security settings, enter the Wireless security key listed on your Wireless Security Card (included in the box).
- Page 10 List of Mobile Broadband Service Providers MOBILE SERVICE Australia Telstra Telstra.internet Telstra.pcpack Telstra.datapack Telstra.extranet Optus – Postpaid connect Optus – Prepaid preconnect Three – Postpaid 3netaccess Three – Prepaid 3services Vodafone – Postpaid vfinternet.au Vodafone – Prepaid vfprepaymbb Crazy John’s purtona.net DoDo dodolns1...
