NetComm NB704 Specifications

Today's Enterprise and SME businesses are constantly battling the unrelenting pressure to do more in less
time. Designed for applications that require high speed Internet or WAN links, such as Voice over IP, Video
Confrencing or Data hosting, the NB704 uses the next generation of SHDSL technology to deliver scalable
bandwidth, beyond the coverage area traditionally serviced by DSL or 2-wire SHDSL services.
The NB704 utilises existing telecommunications infrastructure (two twisted pairs of copper wire, 4-wire) to
enable high-speed symmetrical services with data transfer rates of up to 4.6Mbps (up and downstream), which
translates to higher throughput and productivity.
Features
High Speed Symmetrical Data Transmission on two Twisted Pairs of Copper Wires
Symmetrical Multi-rate Data Transmissions from 144 Kbps up to 4.6 Mbps
Supports PPPoE (RFC2516), PPP (RFC2364), and IP (RFC 2225/RFC1577) over ATM over SHDSL RFC2684 (RFC1483)
Bridged/Routed for both LLC/VC MUX
Operates in Bridge or Router modes.
Allows multiple LAN users to access Internet through Network Address Translation (NAT, IP sharing) simultaneously
Configuration and management by local Telnet, SNMP, and WEB Browser through the Ethernet interface, and remotely through
SHDSL interface
Built-in DHCP server
Firmware upgradeable through TFTP
Ethernet switch with four 10/100Mbps auto-sensing ports for PC or LAN connection
Supports up to 8 PVC's
ITU standard PAM16 Line Code, complies with G.991.2 and G.994.1 standards
Local OAM&P through command line interface via RS-232 Craft port
NETCOMM LIMITED
ABN 85 002 490 486
4 -Wire Modem Router
Up to 4.6Mbps
Symmetrical data
rates.
NAT Security
Bridge or Router
modes.
High Speed Symmetrical Internet Modem/Router
to service your business needs.
• 2-6 Orion Road, LANE COVE, NSW, 2066 • phone 02 9424 2070 • fax 02 9424 2010 • email sales@netcomm.com.au
www.netcomm.com.au
