NetMedia SCE3-IR Specifications

NM-VIDLAMP-HIR
(SCE3-IR)
Day/Night Color w/IR LED's
The NetMedia VIDLAMP-HIR (SCE3-IR) is a day/night color security camera with built-in infrared (IR) LED's that mounts to a
typical round 4 inch junction box and is viewed with a security monitor. IR illumination provides invisible light for the camera
in complete darkness. Other base plates with a 1/2 inch diameter hole for the elbow bracket may be used instead. To view the
camera on a single standard television, use the TV's composite RCA Video Input jack.
Product Includes:
1. Camera Assembly (Camera, IR LED's, Light Sensor, Housing, Housing Cap,
Elbow Bracket, Locking Ring, Base, Gasket, Video Connector, Power Connector).
2. 12V DC 300mA Power Transformer (Center Conductor Positive).
3. Mounting hardware (Mounting Screws, Grounding
Strap, Screw and Compression Ring).
Housing
Available in Ivory only:
Model Camera Type
(SCE3-IR) NM-VIDLAMP-HIR Day/Night Color
Housing Cap
Remove to rotate camera
bracket or to adjust focus.
Elbow Bracket
Adjusts camera angle at base,
screw, and housing. Installs in
1/2" junction box covers.
Locking Ring
Secures elbow bracket to
base at desired position.
FEATURES
Excellent image quality
Sees in complete darkness
No visible red glow
IR LED's turn on/o automatically
Tough aluminum housing
Weather resistant enclosure
Internally routed cables
Mounts to standard electrical xtures
Mounts directly to walls and ceilings
Works in low light conditions
Adjustable camera angles
Tamper resistant wiring
Includes power supply
1 year limited warranty
NetMedia, Inc., 10940 N. Stallard Place, Tucson, Arizona 85737 (520) 544-4567 Fax: (520) 544-0800 Email: sales@netmedia.com www.netmedia.com
Video Connector
Female BNC connector.
SPECIFICATIONS
Camera Lens:
Image Sensor:
Resolution:
Field of View:
Min Illumination:
Infrared Sensitivity:
Infrared Illuminators:
Output Connector:
Power Requirement:
Power Connector:
Housing Size:
Base Size:
Mounting Holes:
Weight:
Security Camera w/IR
Indoor/Outdoor Weather Resistant
5.5mm OD, 2.1mm ID, center positive
Camera Lens
Comes prefocused from
factory but can be adjusted
by rotating in either direction.
Infrared LED's
940nm IR illuminators
provide invisible light for
camera without red glow.
Light Sensor
Automatically turns LED's on
and off according to light level.
Gasket, Base & Screws
Mount to round 4" junction box.
Power Connector
12V DC 300mA, center positive.
Day/Night Color
3.6mm
1/3" CCD
580 lines
72˚ Horizontal
0.3 Lux F1.2
Yes
28 - 940nm IR LED's
Female BNC, 75 Ohm
12V DC, 300mA
3.13" dia., 4" long
4.5" dia., 0.75" high, 0.5" hole
3.5" centers
1 lb.
(subject to change without notice)
MAN-VIDLAMP-HIR REV0707A
