Sony HCD-GPX33 Service Manual page 78

HCD-GPX33/GPX55/GPX77/GPX88
MIC STR
Ref. No. Part No. Description
< VARIABLE RESISTOR >
RV2050 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL MIN MAX)
*************************************************************
A-1907-117-A STR BOARD, COMPLETE
********************
< CAPACITOR >
C2100 1-118-347-11 CERAMIC CHIP 0.1uF
C2103 1-116-720-11 CERAMIC CHIP 10uF
C2104 1-124-584-00 ELECT
C2106 1-118-347-11 CERAMIC CHIP 0.1uF
C2109 1-116-720-11 CERAMIC CHIP 10uF
C2110 1-124-584-00 ELECT
C2115 1-162-927-11 CERAMIC CHIP 100PF
C2116 1-162-927-11 CERAMIC CHIP 100PF
C2117 1-162-927-11 CERAMIC CHIP 100PF
C2118 1-162-927-11 CERAMIC CHIP 100PF
C2119 1-118-345-11 CERAMIC CHIP 0.01uF
C2121 1-118-345-11 CERAMIC CHIP 0.01uF
C2122 1-118-345-11 CERAMIC CHIP 0.01uF
C2175 1-118-345-11 CERAMIC CHIP 0.01uF
C2177 1-118-345-11 CERAMIC CHIP 0.01uF
C2178 1-118-345-11 CERAMIC CHIP 0.01uF
C2179 1-118-345-11 CERAMIC CHIP 0.01uF
C2180 1-118-345-11 CERAMIC CHIP 0.01uF
C2181 1-118-345-11 CERAMIC CHIP 0.01uF
C2182 1-118-345-11 CERAMIC CHIP 0.01uF
C2183 1-118-345-11 CERAMIC CHIP 0.01uF
C2184 1-118-345-11 CERAMIC CHIP 0.01uF
C2185 1-118-345-11 CERAMIC CHIP 0.01uF
C2186 1-118-345-11 CERAMIC CHIP 0.01uF
C2187 1-118-345-11 CERAMIC CHIP 0.01uF
C2188 1-118-345-11 CERAMIC CHIP 0.01uF
C2189 1-118-345-11 CERAMIC CHIP 0.01uF
C2190 1-118-345-11 CERAMIC CHIP 0.01uF
C2191 1-118-345-11 CERAMIC CHIP 0.01uF
C2192 1-118-345-11 CERAMIC CHIP 0.01uF
C2193 1-162-927-11 CERAMIC CHIP 100PF
C2194 1-162-927-11 CERAMIC CHIP 100PF
C2195 1-162-927-11 CERAMIC CHIP 100PF
C2196 1-162-927-11 CERAMIC CHIP 100PF
< CONNECTOR >
CN2102 1-819-866-11 USB CONNECTOR (A) ( A PLAY 5V
CN2103 1-819-866-11 USB CONNECTOR (A)
CN2104 1-784-780-11 CONNECTOR, FFC 19P
CN2105 1-568-854-11 CONNECTOR, FFC 11P
CN2106 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D2100 6-503-720-01 DI 1L0353W61B3MKT01
D2101 6-503-720-01 DI 1L0353W61B3MKT01
D2102 6-503-720-01 DI 1L0353W61B3MKT01
D2103 6-503-720-01 DI 1L0353W61B3MKT01
D2104 6-503-720-01 DI 1L0353W61B3MKT01
D2105 6-500-400-01 DIODE BAV99-215
D2106 6-503-224-02 DI 1L0352V22F3MIT02
D2107 6-500-400-01 DIODE BAV99-215
D2108 6-500-400-01 DIODE BAV99-215
78
Remark
10% 25V
20% 6.3V
100uF 20% 6.3V
10% 25V
20% 6.3V
100uF 20% 6.3V
5% 50V
5% 50V
5% 50V
5% 50V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
10% 25V
5% 50V
5% 50V
5% 50V
5% 50V
500mA)
( B REC/PLAY 5V 500mA)
Ref. No. Part No. Description
D2109 6-503-388-01 DI 1L0352B13F0MIT02
D2110 6-502-970-01 DI DZ2J068M0L
D2111 6-502-970-01 DI DZ2J068M0L
D2113 6-502-970-01 DI DZ2J068M0L
D2115 6-503-224-02 DI 1L0352V22F3MIT02
D2116 6-503-720-01 DI 1L0353W61B3MKT01
D2117 6-503-224-02 DI 1L0352V22F3MIT02
D2118 6-503-720-01 DI 1L0353W61B3MKT01
D2120 6-503-224-02 DI 1L0352V22F3MIT02
D2121 6-500-400-01 DIODE BAV99-215
D2122 6-500-400-01 DIODE BAV99-215
D2123 6-500-400-01 DIODE BAV99-215
D2124 6-502-970-01 DI DZ2J068M0L
D2125 6-502-970-01 DI DZ2J068M0L
D2127 6-502-970-01 DI DZ2J068M0L
D2128 6-503-720-01 DI 1L0353W61B3MKT01
D2129 6-503-720-01 DI 1L0353W61B3MKT01
D2130 6-503-720-01 DI 1L0353W61B3MKT01
D2131 6-503-720-01 DI 1L0353W61B3MKT01
D2132 6-503-720-01 DI 1L0353W61B3MKT01
D2133 6-503-720-01 DI 1L0353W61B3MKT01
D2134 6-503-720-01 DI 1L0353W61B3MKT01
D2135 6-503-720-01 DI 1L0353W61B3MKT01
D2136 6-503-720-01 DI 1L0353W61B3MKT01
D2137 6-503-720-01 DI 1L0353W61B3MKT01
< FERRITE BEAD >
FB2100 1-500-283-11 INDUCTOR, FERRITE BEAD
FB2101 1-500-283-11 INDUCTOR, FERRITE BEAD
FB2102 1-500-283-11 INDUCTOR, FERRITE BEAD
FB2103 1-500-283-11 INDUCTOR, FERRITE BEAD
< IC >
IC2100 6-719-142-01 IC TC62D723FNG
< JUMPER RESISTOR >
JR2100 1-216-296-11 SHORT CHIP
JR2101 1-216-296-11 SHORT CHIP
JR2102 1-216-296-11 SHORT CHIP
JR2103 1-216-296-11 SHORT CHIP
JR2104 1-216-296-11 SHORT CHIP
JR2105 1-216-296-11 SHORT CHIP
JR2106 1-216-296-11 SHORT CHIP
JR2107 1-216-296-11 SHORT CHIP
JR2108 1-216-296-11 SHORT CHIP
JR2109 1-216-296-11 SHORT CHIP
JR2110 1-216-296-11 SHORT CHIP
JR2111 1-216-296-11 SHORT CHIP
JR2112 1-216-296-11 SHORT CHIP
JR2113 1-216-296-11 SHORT CHIP
JR2114 1-216-296-11 SHORT CHIP
JR2115 1-216-296-11 SHORT CHIP
JR2116 1-216-864-11 SHORT CHIP
JR2117 1-216-296-11 SHORT CHIP
JR2118 1-216-296-11 SHORT CHIP
JR2119 1-216-296-11 SHORT CHIP
JR2120 1-216-296-11 SHORT CHIP
JR2121 1-216-295-91 SHORT CHIP
JR2122 1-216-296-11 SHORT CHIP
JR2123 1-216-296-11 SHORT CHIP
Remark
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
