TeachLogic OM-20 User Manual

Download this manual

TeachLogic's Ovation Handheld Microphone (OM-20) is a wireless mic that uses special DECT (Digital Enhanced Cordless

Telecommunications) radio technology to transmit crystal clear audio throughout your classroom. With its secure connection,

robust design and simple to use features, the OM-20 is perfect for any classroom. Together with the compatible TeachLogic

amplifier/ receiver (the OA-50), you can be sure every student can accurately and effortlessly hear comments, questions, and

answers from their fellow classmate no matter where they are in the classroom.

1. Logo Window and Indicator Light

2. Push to Talk (PTT) Button

3. Power Button ON / OFF

User Guide: OM-20

DIAGRAM 1: OM-20 Controls and Features

Bottom View

4. PTT ON / OFF Switch

5. USB-C Charging Port

6. Battery Compartment Cover

OM-20, r 2022.10.21 Page 1

Need help?

Do you have a question about the OM-20 and is the answer not in the manual?

Page 1 Telecommunications) radio technology to transmit crystal clear audio throughout your classroom. With its secure connection, robust design and simple to use features, the OM-20 is perfect for any classroom. Together with the compatible TeachLogic amplifier/ receiver (the OA-50), you can be sure every student can accurately and effortlessly hear comments, questions, and answers from their fellow classmate no matter where they are in the classroom.
Page 2 Li-ion 5. OC-20 Power Indicator Light 6. Charging Dock Indicator Lights DIAGRAM 4: Pairing Buttons 2. OM-20 Push to Talk (PTT) Button Requires simultaneous press and hold for 3 sec- 3. OM-20 Power Button ON / OFF onds to enter pairing mode a.
Page 3  Battery Life: The OM-20’s battery life is approximately 8 hours of active use on a full charge. If your mic battery is low, the mic logo window will display a solid red light when it has 10% battery life remaining. When critically low (last 5% of battery life) the red light will blink.
Page 4 OM-20. To use this feature, you must first switch your OM-20 into PTT mode. 1) On the bottom of the OM-20 is a small switch flush with the bottom of the mic. With the mic front side facing up, slide the switch to the left to turn PTT mode on.
