Basic Maintenance Instructions
For Islander Trout Series Fly Reels
Thank you for purchasing an Islander Reel. Provided that
you the maintenance points are followed, you reel will give
you a lifetime of trouble-free coperation.
1. After each outting, the reel should be rinsed off with clean, warm water. Peri-
odically, a more complete cleaning should be done with warm soapy water fol-
lowed by the clean, warmwater rinse.
2. Periodically, check the surface of the Teflon disk (see reel blow up #21) and
make sure that there is no grit between the Teflon disk and the surface of the
clutch (#20).
3. Occasionally, inspect the bearings (#19) & (#23), and make sure that grit has
not attached itself to the bearings. Grit will get inside the bearings and cause
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Islander Trout Series
Summary of Contents for Islander Trout Series
- Page 1 Basic Maintenance Instructions For Islander Trout Series Fly Reels Thank you for purchasing an Islander Reel. Provided that you the maintenance points are followed, you reel will give you a lifetime of trouble-free coperation. 1. After each outting, the reel should be rinsed off with clean, warm water. Peri- odically, a more complete cleaning should be done with warm soapy water fol- lowed by the clean, warmwater rinse.
- Page 2 Disassembly 1. Remove the spool (#25) from the frame (#13) by using the release latch (#31) located under the cover cap (#33) on the face of the spool. 2. Remove the set screw (#2) from under the drag adjust- ment knob, using the allen wrench (#6) supplied with your reel.
- Page 3 Lubrication & Cleaning Pawl Assembly • Wash grit away from bottom of pawl (#9), and away from pawl springs (#12). • Using a light oil, lubricate around the pawl screw (#11), around the pawl (#9) and around the pawl springs (#12). Pawl Assembly Clutch Assembly •...
- Page 4 Lubrication & Cleaning Clicker Assembly • Wash grit away from bottom of pawl (#9), and away from pawl springs (#12). • Using a light oil, lubricate around the pawl screw (#11), around the pawl (#9) and around the pawl springs (#12). Clicker Assembly Subspindle and Drawbar •...
- Page 5 External Components • Keep the quick release latch clean of grit (#31), Keep the set screw holes in the back of the frame free of grit (#13). • Apply a drop of light oil to the quick release latch (#31). Apply a thin layer of light grease on the outside of the frame O-Ring (#3) and a drop of light grease on the inside of the threaded hole on the dragknob (#1).
- Page 6 Reassembly 1. Place the clutch bearing (#19) onto the spindle the clutch (#20) over the clutch bearing (#19) as per your choice of left for right hand retrieve. (See bottom of pre- vious page.) 2. Replace the subspindle (#22) onto the spindle (#16). Place the drawbar (#24) inside the subspindle, so Chat the drawbar sits flush with the subspindle.
-
Page 7: Miscellaneous Information
Miscellaneous Information Islander recommends the use of SuperLube brand oil and grease with Teflon for all lubricating applications. Super- Lube with Teflon is manufactured by Synco Chemical Corp. N.Y Teflon is a registered trademark of E.I. duPont deNemours & Co. - Page 8 TS1-3 Assembly and Part List 1. Dragknob 9. Pawl 17. Clicker Spring 25. Spool 2. Set screw 10. Pawl Sleeve 18. Clicker Spring Screw 26. Handle Base Screw 3. O-Ring 11. Pawl Screw 19. Clutch Bearing 27. Handle Base 4. Clicker Bu on 12.
