5. Turn the lock nut clockwise until tight against the base of
the brush (Fig. 5).
Fig. 5
6. Adjust the distance between the brush and the quick-
connect collar before closing the cam-lock (Fig. 3).
7. Attach the shoulder
strap to the sky lance and secure in
place using the thumb screw (Fig. 6).
Fig. 6
Strap
Thumb
screw
8. Snap the desired nozzle onto the Quick-Connect collar
until it clicks into place (Fig. 7).
NOTE: Nozzles are not included with this tool. Visit
snowjoe.com for pressure washer quick-connect nozzles.
Lock nut
Nozzle
9. Connect the high-pressure hose from your pressure
washer to the water inlet on the bottom
(Fig. 8). Alternatively, use the quick-connect to
pressure hose adapter for use with a quick-connect high-
pressure hose (Fig. 9).
Fig. 8
Fig. 9

Operation

1. Use the cam-locks to adjust
length.
NOTE: Never extend the lance sections
marked in red.
4
Quick-Connect collar
Water inlet
Quick-Connect to
M22 high-pressure
hose adapter
Water inlet
the sky lance to your desired
Fig. 7
of the sky lance
M22 high-
High pressure
hose
Quick-Connect
high-pressure
hose
beyond the lines
