Technical Data - SNOWJOE SUNJOE SPX-EPB1 Operator's Manual

Know Your 18 - ft Telescoping Pressure Washer Sky Lance
Read the owner's manual and safety instructions carefully before operating this sky lance. Compare the illustration below to the
unit in order to become familiar with the location of the various controls and adjustments. Save this manual for future reference.
1
3
4
5
6
7
8
10

Technical Data

Length ........................................................5' - 18' (1.5 m - 5.5 m)
Max Pressure ............................................................... 4200 PSI
Max Flow ..................................................... 6.6 GPM (25 L/min)
2
11
12
13
14
9
Max Temperature ................................................... 140°F (60°C)
Net Weight .......................................................... 9.9 lbs (4.5 kg)
2
1. Brush
2. Quick-
Connect collar
3. Brush mount
4. Lance section
5. Cam-lock
6. Foam grip
7. Shoulder
strap mount
8. Safety switch
9. Trigger
10. Water inlet (high-
pressure hose
connection)
11. S4 + S5
allen keys
12. Quick-Connect
to M22 high-
pressure hose
adapter
13. U-pin
14. Shoulder strap
