Summary of Contents for SNOWJOE Sunjoe SPX202C-RM
- Page 1 CORDLESS PRESSURE WASHER 725 PSI MAX* | 1.05 GPM MAX* | 36 V OPERATOR’S MANUAL Model SPX202C-RM A Division of Snow Joe , LLC ® Form No. SJ-SPX202C-880E-RM-M-V1 © 2021 by Snow Joe , LLC SAVE THESE INSTRUCTIONS ® All rights reserved. Original instructions.
-
Page 2: General Safety
Snow Joe + Sun Joe customer service center at ® ® 1-866-SNOWJOE (1-866-766-9563). WARNING! High-pressure jets can be dangerous if WARNING! subject to misuse. The jet must not be directed at persons, When using the pressure washer, basic pets, live electrical equipment, or the appliance itself. -
Page 3: Electrical Safety
® ® ® Damaged or entangled cords increase the risk of electric customer service center at 1-866-SNOWJOE shock. (1-866-766-9563). Incorrect reassembly poses a risk of 4. Battery charger is for indoor use only. Do not charge the electric shock, electrocution or fire. -
Page 4: Product Description
13. The longest life and best performance can be obtained if the integrated battery is charged when the air temperature is between 64.4ºF – 75.2ºF (18ºC – 24ºC). Do not charge the battery pack when the air temperature falls below 50ºF (10ºC) or above 104ºF (40ºC). -
Page 5: Safety Symbols
Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S MANUAL(S) – Read, understand, SAFETY ALERT –... -
Page 6: Technical Data
Know Your Cordless Pressure Washer Read the owner’s manual and safety rules carefully before operating the pressure washer. Compare the illustration below to the pressure washer in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. -
Page 7: Carton Contents
Snow Joe + Sun Joe customer service center at ® ® 1-866-SNOWJOE (1-866-766-9563). Fig. 2 NOTE: Do not discard the shipping carton and packaging material until you are ready to use your new cordless Trigger gun pressure washer. The packaging is made of recyclable materials. -
Page 8: Before Using
indicator. To check the battery capacity, push the button Fig. 3 (Fig. 5). The charge indicator system indicates the battery status of the pressure washer as the table shows below. Push to release Fig. 5 RELEASE LED indicator Trigger gun Push the button to check the battery capacity... -
Page 9: Operation
NOTE: The machine is not suitable for connection to washer. Connect the charger plug into an appropriate AC outlet to start charging (Fig. 6). the potable water main. Fig. 7 Fig. 6 Battery charger Charge indicator LED Garden hose Garden hose This end to Water inlet Charging socket... - Page 10 Fig. 12 WARNING! The intake water temperature must not exceed 104ºF/40ºC. The water supply must not exceed 0.7 MPa. 3. A water bladder with connection hose is equipped in case there's no water source close to the working area. Fill the Water inlet water bladder and connect it with the water hose (Figs.
- Page 11 Fig. 14 Pencil spray RELEASE Trigger Nozzle tip Safety lock Nozzle tip Fan spray adjustment knob 5. Keeping the trigger pressed, turn the switch to the ON (I) Fig. 16 position to start the pressure washer (Fig. 15). Fig. 15 WARNING! Do not adjust the nozzle while the trigger is squeezed.
-
Page 12: Shutting Down
Storage Fig. 18 Volume + CAUTION! Always store your pressure washer in a location Volume – where the temperature will not fall below 32ºF (0ºC). The pump in this machine is susceptible to permanent damage if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE WARRANTY. -
Page 13: Maintenance
Maintenance Disposal Recycling the washer CAUTION! Before working on the pressure washer, switch • Do not dispose of electrical appliances as unsorted off the unit. municipal waste. Use separate collection facilities. 1. To ensure good performance, check and clean the filter •... -
Page 14: Service & Support
Snow Joe ® WARNING! Any changes or modifications to this Sun Joe customer service center at 1-866-SNOWJOE ® unit not expressly approved by the party responsible for (1-866-766-9563). compliance could void the user's authority to operate the Model + Serial Numbers equipment. -
Page 15: Troubleshooting
• Pump seals worn out. • Please call the Snow Joe + Sun Joe customer ® ® service center at 1-866-SNOWJOE (1-866-766-9563) for assistance. Machine stops • Battery is flat. • Charging the battery. • Nozzle partially blocked. • Clean the nozzle. -
Page 16: Optional Accessories
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe + Sun Joe to provide notice of such ® ® changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe + Sun Joe customer ® ® service center at 1-866-SNOWJOE (1-866-766-9563). - Page 17 NOTES...
- Page 18 NOTES...
- Page 19 To obtain a replacement part or product, please visit Some states do not allow exclusions of incidental or consequential snowjoe.com/help or email us at help@snowjoe.com for damages so the above exclusions may not apply in all states. This instructions. Please be sure to register your unit beforehand warranty may give you specific legal rights in your state.
- Page 20 sunjoe.com...
