- Page 1 Operating Instruction MEAT AGER MX1000 Read the instruction carefully before using V2021/11...
-
Page 2: Table Of Contents
S t r u c t u r e Di a g r a m-------------------------------------------------2 Wa r ning-----------------------------------------------------------------3 P r o d u e t in t r o d u ct i o n------- ------ ------- ------- ------ ------- ------ -4 I ns t a 11 a t i o n--------------------------------------------------------------5 H o w to Use-----------------------------------------------------------7 T e c h n i c a I Sp e c i f i c a t i o ns------- ------ ------ ------ ------ ------ -----8... -
Page 3: S T R U C T U R E Di A G R A
Structure Diagram Lock Control panel UVC-system Internal LED light Hanger S-Hook Grid shelves Activated carbon filter Salt brick Salt brick tray Adjustable-height feet - 2 -... -
Page 4: Wa R Ning
Warnings 1. Please read this instruction carefully before installation and using. This instruction manual is an integral part of the machine and must be kept for any further consultation. 2. Do not use the equipment for any purpose or in any way other than described in this manual. -
Page 5: P R O D U E T In T R O D U Ct I O
Product Introduction MX1000 Meat Ager is committed to creating an internationally recognized meat maturing environment. This equipment is equipped with precise intelligent temperature, humidity control system (temperature 1~4°C, humidity 60%-90%), and Himalayan salt brick, which makes cooked meat more flavorful. The equipment uses UVC lamp sterilization and high perspective anti-ultraviolet insulating glass, and is equipped with activated carbon to filter the air. -
Page 6: I Ns T A 11 A T I O
Installation 1. In order to prevent the oil contained in the hermetic compressor from flowing into the cooling circuit, it is necessary to always carry store and handle the machine in a vertical position during the transportation. 2. To prevent injury or damage to the unit, the appliance should be unpacked and set by two or more people. - Page 7 Installation Instruction Step 1, Remove the package and the bottom wooden support. Pass the rope through the bottom of the machine and tighten the rope, as shown in the figure (F1), pull the machine from the wooden support as shown in the figure(F2).
-
Page 8: How To Use
Warning: Do not use extension cords. Do not connect more than one appliance on the same electrical outlet. Product problems caused by this reason will not under warranty! Safety lock The lock in the appliance door is equipped with a safety mechanism. Be sure to lock it while it is ripening. -
Page 9: T E C H N I C A I Sp E C I F I C A T I O
High temperature alarm Alarm for long time door opening (more than 4 minutes) Low temperature alarm Low temperature alarm High humidity alarm Technical Specifications 220-240V~50/60Hz Voltage Model MX1000 0.8A Temperature 1℃~4 ℃ Current Humidity 60%-90% 160W Power Net weight 102 KG... -
Page 10: Main T En A N C
Maintenance: Cleaning • Before carrying out cleaning, remove the power plug. Clean the inside and outer walls with lukewarm water and a little detergent. • Do not use abrasive or acid cleaners or chemical solvents. • Use a glass cleaner to clean the glass surfaces and a commercially available stainless-steel cleaning agent for the stainless-steel surfaces. -
Page 11: Disposal
Disposal The appliance contains reusable materials and should be disposed of properly - not simply with unsorted household refuse. Appliances which are no longer needed must be disposed of in a professional and appropriate way, in accordance with the current local regulations and laws.
