Navitar 1-51204 Dimensional Drawing

3.35 [85.1]
2.34 [59.3]
1.11 [28.1]
2.79 [70.8]
n
2.03 [51.5]
n
1.73 [43.9]
n
1.50 [38.1]
USED ON:
MATERIAL:
DIMENSIONS ARE IN INCHES
AND INCLUDE CHEMICALLY
APPLIED OR PLATED FINISHES
DEC. .XXX
FINISH:
DEC. .XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARP EDGES
.005 MIN. .010 MAX
CHAMFER ALL THREADS
MAX. SURF. ROUGHNESS
~
30 TO ROOT DIAM.
6.66 [169.1]
6.56 [166.6]
13/16-32 UN - 2B
1.88 [47.6]
5.26 [133.5]
P/N SUFFIX DEFINITION THE CONTENTS OF THIS
UNLESS OTHERWISE
DOCUMENT ARE PROPRIETARY
SPECIFIED
-1 CONVERSION COATING
TO NAVITAR, ITS USE IS
-2 PAINTING
AUTHORIZED ONLY FOR
-3 MARKING
RESPONDING TO REQUEST
-R REWORK
FOR QUOTATION OR
TOLERANCES:
1:1
SCALE: PERFORMANCE OF WORK FOR
`
.005
`
DR.: R. PODLENA
.010
0.0
`
1/64 CH.: P. BONAFEDE
`
30'
APP.:
.003 TIR
0.0
11/19/2002
DATE DR.:
32
DO NOT SCALE DRAWING
REV CHANGE RECORD AND DATE CH
A
RELEASE 10/20/03
+ .000
n
1.312
- .001
.28 [7.2]
ROCHESTER, NEW YORK
NAVITAR
MOTORIZED (5PH) 12X & 3mm FF
inch 1.0
w/COAX PORT & DUAL 2 POSITION
LS
SIZE
mm 25.0
1-51204
B
1 1
SHEET OF
[ ]
+ .0
33.3 - .0
REV
A
