High Flow Side Mesh
Tank Screen
Installation and Specification Guide
PRODUCT DETAILS
Code
Size
Country
High Flow, Side Mesh Tank Screens ensure you get
maximum water flow through your tank screen even
TATS15
400mm / 16in
as debris loads start to build.
Global
TATS16
500mm / 20in
The mesh side walls allow water to flow into the tank
through all directions, which means more water in
your tank, and less chance of splashing.
rainharvesting.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blue Mountain RAIN HARVESTING TATS15
Summary of Contents for Blue Mountain RAIN HARVESTING TATS15
- Page 1 High Flow Side Mesh Tank Screen Installation and Specification Guide PRODUCT DETAILS Code Size Country High Flow, Side Mesh Tank Screens ensure you get maximum water flow through your tank screen even TATS15 400mm / 16in as debris loads start to build. Global TATS16 500mm / 20in...
- Page 2 Installation WHAT’S IN THE BOX? TOOLS/MATERIALS YOU MAY REQUIRE High Flow Side Mesh Tank Screen Screws Screwdriver or drill HIGH FLOW SIDE MESH TANK SCREEN 1 - If you already have a tank screen installed, remove it prior to installing the new tank screen. 2 - Place the Tank Screen into the inlet hole of the tank, making sure it is approximately centred in the hole, and that the rim of the tank screen covers the inlet fully.
- Page 3 Product Specifications High Flow Side Mesh Tank Screen Dimensions & Pipe Fittings COUNTRY CODE Tank Hole Size 365-382 TATS15 14.37"-15.04" 16.3" 15.5" 2.3" 3" 14.04" Global 455-481 TATS16 17.91"-18.94" 19.9" 19.4" 2.3" 3" 17.61" All dimensions are in mm unless otherwise stated. rainharvesting.com...
- Page 4 Maintenance You should regularly inspect your Tank Screen and remove any leaves or debris. For a more thorough clean, unscrew your Tank Screen and hose it off before reattaching to your tank. We recommend covering the hole in your tank while cleaning the screen to prevent mosquitoes getting in. For even easier maintenance, consider using a Maintenance Tray –...
- Page 5 For more information or to find out how we can help, just give us a call on +61 7 3248 9600 Or visit our website at rainharvesting.com...
