Summary of Contents for ZANE ARTS PS-033
- Page 1 P S - 0 3 3 / L O L O M A N U A L - V e r 1. 0 0...
- Page 2 ■ ITEMS INCLUDED Please check the contents of this set before fully opening the tent. If you find something missing, please contact the store where you purchased it or ZANE ARTS directly. Long front frame x 1 Short front frame x 1...
- Page 3 ■ ABOUT THIS PRODUCT Please familiarize yourself with this product before use. Pegs not include Pegs are not included. Please prepare the following recommended pegs ahead of time. 【 Recommended Type · Required Number 】 ● TO-528 / GRART STAKE 28 × 22 Apply seam sealant Seam tape cannot be attached to the joint at the tip of the indoor ceiling.
- Page 4 Waterproofing performance is reduced The surface is treated with silicone water repellent, but after use, the water repellent performance will deteriorate and rain will eventually penetrate the fabric. Please note that the water repellency cannot be maintained long term. Waterproof performance of the back side is not affected, so even if water repellency deteriorates, there is no issue using it as it is.
- Page 5 Use of a wood stove is absolutely prohibited. Chemically treated fibers are used in the fabric of this product. Chemically treated fibers may liquefy when burned, the liquefied fabric may stick to skin and cause serious burns. Never bring fire close to tents, shelters or tarps.
- Page 6 ■ PRECAUTIONS FOR SETUP AND USE Please follow these guidelines to avoid property damage and to ensure the safety of yourself and others. INDICATES SITUATIONS THAT MAY RESULT IN DEATH OR SERIOUS INJURY. DANGER ● Fire is strictly prohibited near tents, shelters, and tarps. The risk of fire, oxygen deficiency, carbon monoxide poisoning, etc.
- Page 7 INDICATES SITUATIONS THAT MAY RESULT IN MINOR INJURY OR PROPERTY DAMAGE. CAUTION ● Not for permanent use. If this product is set up permanently, it will deteriorate and be damaged in a short period of time due to the effects of ultraviolet rays and other elements. ●...
- Page 8 ● When extending poles or frames, make sure each section is inserted securely. Assembling the product incorrectly can lead to damage. ● When handling poles or frames, pay attention to your surroundings and be careful not to hit or damage something around you.
- Page 9 ■ PRECAUTIONS FOR TEARDOWN AND AFTER USE CARE Please follow these guidelines to avoid property damage and to ensure the safety of yourself and others. INDICATES SITUATIONS THAT MAY RESULT IN MINOR INJURY OR PROPERTY DAMAGE. CAUTION ● When taking down, work with two or more people. ●...
- Page 10 ● After each use, clean the fabric and dry thoroughly before storing. If stored dirty or wet, colors may transfer, moldy odors may form, and the waterproof coating and seam tape may come off. ● Frames, poles, and other metal parts should also be thoroughly dried before storing.
- Page 11 ■ SETUP PROCEDURES Follow the numbered steps to set up. 【 Prepare in Advance 】 ※ Prepare Pegs and Hammer Recommended Pegs • Quantity TO-528 ／ GRART STAKE 28×22 ※ Close all zippers Install the Center Pole Install the Frame Install Inner Tent Attach Ropes and Drive Pegs...
- Page 12 1 INSERT THE CENTER POLE A : Make a square by driving pegs (GRART STAKE 28) through the four gray corner loops that are attached to the gray building tape (webbing). ※ Make it as square as possible. A base that is askew will result in a distorted tent, making it more prone to damage.
- Page 13 2 INSERT THE CENTER POLE B: Stand the center pole in the room and push up into the apex. C: Drive pegs (GRART STAKE 28) into the remaining two side corners to complete. Peg (GRART STAKE 28) 45˚ Center pole Drive pegs at 45˚...
- Page 14 1 INSTALL THE FRAME A: Insert the longest frame (long front frame), with the silver ends, into the sleeve with the gray binding. Gray tape B : Insert corner clips with gray rope into both ends of frame. Frame with Silver ends C: Clip (2 places) Sleeve...
- Page 15 2 SETTING UP THE SHORT FRAME D: Insert the second to longest frame (the short front frame) through the sleeve with black binding. E : Insert corner clips with black rope on both ends of frame. Black Binding F : Attach clips (4 places) Sleeve Clip Clip...
- Page 16 3 SETTING UP THE BRIDGE FRAMES G: Insert frames (bridge frame) with locking grommet tips into grommets above entrance on both sides. H : Insert clips on bottom side corners into ends of bridge frames on both sides. I: Attach clips (5 locations) to bridge frame. Repeat on opposite side.
- Page 17 4 SETTING UP THE REAR FRAME J: Peg down two front corners (GRART STAKE 28). K : Insert shortest frame (rear frame) through back sleeve. L: Insert back side clips into ends of bridge frames on both sides. M: Attach clip (2 places) N : Pull both back corners out and peg down (GRART STAKE 28).
- Page 18 1 ATTACH ROPES AND DRIVE PEGS Attach 2 m and 3 m ropes according to the diagram below. The 2 m ropes are only used in 2 places, all others are 3 m. Attach the rope to rings where available, where rings are not available, attach to webbing.
- Page 19 2 ATTACH ROPES AND DRIVE PEGS A: Lasso the webbing loop. Lasso the B : Peg down two ropes with one peg. webbing loop. C: Peg down three ropes with one peg. D: Peg down one rope with one peg. ※...
- Page 20 1 INSTALL INNER TENT A: Hang inner tent hook on D ring of center pole, adjust height as needed and secure with hook-and-loop tape. (the D ring can be easily reached by tilting the pole diagonally). B: Fix the inner tent to the center pole with cords (2 places). Hook Adjust Secure with...
- Page 21 2 INSTALL INNER TENT C: On exterior of inner tent, hook upper rear hooks to rings on main tent, adjust as needed (2 places). D: On exterior of inner tent, hook bottom rear hooks to rings on main tent, adjust as needed (2 places).
- Page 22 3 INSTALL INNER TENT E: On exterior of inner tent, hook bottom middle hooks to rings on main tent, adjust as needed (2 places). F: On exterior of inner tent, hook bottom front hooks to rings on main tent, adjust as needed (2 places). Adjuster Adjuster...
- Page 23 4 INSTALL INNER TENT G: After installing inner tent, tension all guy lines. Set up is complete. Slide tensioner to apply tension.
- Page 24 Moisture and dirt may interfere with repairs. Items that are not clean and dry upon arrival for repair will incur additional charges at their own expense for cleaning. Thank you for your understanding. ZANE ARTS, Inc. 7190-2 Shimauchi, Matsumoto, Nagano 390-0851 Phone: 0263-87-2955 FAX: 0263-87-2966 info@zanearts.com...
