Summary of Contents for ZANE ARTS DT-002
- Page 1 D T - 0 0 2 / O K I T O M A - 2 M A N U A L - V e r 2 . 0 1...
- Page 2 ■ ITEMS INCLUDED Please check the contents of the set before fully opening the tent. If you find something missing, please contact the store where you purchased it or us directly. Bridge Frame × 2 Long Frame × 2 Fly Sheet Inner Tent ×1 ×1...
- Page 3 ■ ABOUT THIS PRODUCT Please take some time to understand the characteristics of this product before using it. Pegs not include Pegs not include, please prepare the following recommended pegs and the required number of pegs in advance. 【 Recommend Required Number 】...
- Page 4 Wrinkles caused by folding are noticeable Commonly used chemically treated fibers used in tents, shelters and tarps are prone to creases. In particular, the fabric in this product has noticeable wrinkles due to the color, thickness, and surface processing of fabric. Please note that it does not affect performance in any way.
- Page 5 Do not remove the fire prohibition tag Do not cut or remove the fire-prohibited tag sewn into the product. Products without a fire-prohibited tag cannot be guaranteed or repaired.
- Page 6 ■ PRECAUTIONS FOR SETUP AND USE Be sure to read and understand the following contents before use to prevent harm to the user and others, and damage to property. INDICATES CONTENT THAT MAY RESULT IN DEATH OR SERIOUS INJURY. DANGER ● ...
- Page 7 INDICATES CONTENT THAT MAY CAUSE INJURIES OR PROPERTY DAMAGE. WARNING ● Not for permanent use. If this product is set up permanently, it will deteriorate and be damaged in a short period of time due to the effects of ultraviolet rays and other elements. ●...
- Page 8 ● When extending poles or frames, make sure each section is inserted securely. Assembling the product incorrectly can lead to damage. ● When handling poles or frames, be careful not to hit or damage something around you and pay attention to your surroundings.
- Page 9 ■ PRECAUTIONS FOR TEARDOWN AND AFTER USE CARE Be sure to read and understand the following contents before use to prevent harm to the user and others, and damage to property. INDICATES CONTENT THAT MAY CAUSE MINOR INJURIES OR PROPERTY DAMAGE. WARNING ●...
- Page 10 ● When folding a frame or pole with a built-in cord (cord), begin folding from the center, this will reduce the wear on the bungee cord by not applying extra tension to the cord. ● After use, clean the fabric and allow it to dry thoroughly before storing.
- Page 11 ■ SETUP PROCEDURES Set up according to the numerical order. 【 Prepare in Advance 】 ※ Ready Pegs and Hammer Recommed pegs TO-518 / GRART STAKE 18 × 20 ※ Close all zippers Setting up the Bridge Frames Attaching the Ropes Setting up the Long Frames Pegging Down the Tent...
- Page 12 SETTING UP THE BRIDGE FRAMES Assemble all frames (6 in total) A: Take the long frame with gray ends and insert it into the grommets in the webbing that has gray rope attached to it. (both ends) B: Attach clips (9 locations) to first frame. Repeat on other frame.
- Page 13 SETTING LONG FRAME A: Insert long frames into upper sleeves. B: Insert both ends into grommets. C: Attach clips (2 locations) to first frame. Sleeve Repeat on other frame. Long Frame Black Rope Clips × 2 Insert into the inner grommet The outer grommet is a spare...
- Page 14 SETTING UP THE SHORT FRAMES A: Insert remaining short frames into side sleeves. B: Insert both ends into grommets. C: Clip and wind the intersection (2 locations) Repeat on both sides. Short Frame Black Rope Insert into the inner grommet The outer grommet is a spare Wrap intersecting frame poles together...
- Page 15 ATTACHING THE ROPES Setting rope A: Wrap webbing loop around frame (8 locations) Attach to B: Attach a 2.5m rope to the end of the end of the webbing or to the ring (8 locations). the webbing C: Attach a 1.5m rope to the end of or to the ring the webbing (4 locations).
- Page 16 DRIVE PEGS Drive pegs intot the ground in numerical order A: Peg down sections 1- 4, then peg down sections 5-8 while pulling in the direction of the arrows. B: Peg down sections 9 -12 without over-tensioning. Then peg down the tension cords in sections 13-20.
- Page 17 1 INSTALLING THE INNER TENT (PREP) A: Determine the front and back of the inner tent. The side with the logo is the front. ※ The main tent is symmetrical, so it can be installed either way. B: The two bottom corners on the front can either be pegged down or hooked into place.
- Page 18 2 INSTALLING THE INNER TENT C: Pass the ceiling toggles through the O-rings on the main body (4 locations). Latch hooks D, E, and F, respectively, to the bottom corner O-rings on the main tent. Ring Hook Ring ※ The webbing in Hook section F, can be unhooked and pegged down as well.
- Page 19 1 INSTALLING THE FOOTPRINT (PREP) A: Determine the top and bottom of the footprint. The shiny side is the top. B: When using the protective sheet as a base for the inner tent, place it under the inner tent. When using it as a living sheet, lay it in front of the inner tent. The shiny side is the top.
- Page 20 2 INSTALLING THE FOOTPRINT C: Wrap the elastic loops from each corner around the pegs holding down the main tent. D: When using the protective sheet as a base for the inner tent, unfasten the buckle at the D ring, pass the webbing through the elastic loop and refasten.
- Page 21 SETTING UP THE PANEL AWNING ※ The two poles and two pegs required to set up the panel awning are sold separately. A: Insert the tip of the pole into the corner ring of the main panel. B: Use the 2.5m rope to peg down. Fasten the buckle Ring to prevent drooping.
- Page 22 ATTACHING SUPPLEMENTARY ROPES The tent can be stabilized on windy days by attaching the 2.5m ropes to the metal rings (3 rings per side) located on the clips attached to the center of the bridge frame. Ring Attach a rope to the center point or to the two adjacent points and peg down.
- Page 23 ■ WARRANTY AND REPAIR If you find any defects in the product, please contact the store where you purchased it or us directly. We will replace or repair any item found to have a manufacturing defect free of charge. We will repair products with damage caused by wear and aging at a reasonable price.
