- Page 1 O w ne rs M anu al E N G / V e r 1 . 0 0 A L L W E A T H E R F O U R W I N G T A R P T P - 0 0 3 / G E U...
- Page 2 ■ Items Included Please check the contents of the set before fully opening the tent. If you find something missing, please contact the store where you purchased it or us directly. Main pole x2 Side pole x 2 Tent body Tarp tale x 1 Y-Peg Rope rope...
- Page 3 ■ About this product Please take some time to understand the characteristics of this product before using it. Use of a wood stove is absolutely prohibited. Chemically treated fibers are used in the fabric of this product. Chemically treated fibers may liquefy when burned, the liquefied fabric may stick to skin and cause serious burns.
- Page 4 Waterproofing performance is reduced The surface is treated with silicone water repellent, but after use, the water repellent performance will deteriorate and rain will eventually penetrate the fabric. Please note that the water repellency cannot be maintained long term. Waterproof performance of the back side is not affected, so even if water repellency deteriorates, there is no issue using it as it is.
- Page 5 For 3 seasons of use This product is not designed to withstand snowfall or low temperatures. Do not use in low temperatures where the zippers may freezes or in snow. Do not remove the fire prohibition tag Do not cut or remove the fire-prohibited tag sewn into the product.
- Page 6 ■ Precautions for setup and use Be sure to read and understand the following contents before use to prevent harm to the user and others, and damage to property. Indicates content that may result in death or serious injury. Danger ●Fire is not allowed in tents, shelters, and tarps. It is extremely dangerous as there is a risk of fire, oxygen deficiency, carbon monoxide poisoning, etc.
- Page 7 Indicates content that may cause injuries or property damage. Warning ●Not for permanent use. If this product is set up permanently, it will deteriorate and be damaged in a short period of time due to the effects of ultraviolet rays and other elements. ●Set up on a flat surface with good drainage.
- Page 8 ●When setting up, be prepared for wind gusts and be sure that the main body and frame don’t fly away by keeping your hands on the frame and main body while working. ●When extending poles or frames, make sure each section is inserted securely.
- Page 9 ■ Precautions for teardown and after use care Be sure to read and understand the following contents before use to prevent harm to the user and others, and damage to property. Indicates content that may cause minor injuries or property damage. Warning ●When taking down the product, be sure to have two or more people.
- Page 10 ●After use, clean the fabric and allow it to dry thoroughly before storing. If it is stored with dirt or moisture uncleaned, it may cause colors to transfer or mold odors to form, and may cause the seam tape to come off and diminish its waterproofness.
- Page 11 ■ Setup procedures Set up according to the numerical order. 【Prepare in Advance】 *Make a loop on pegs with commercially available rope φ2mm ・ 20cm Set the main poles Set the side poles Peg down the 4th corners Set the Tarp Tail...
- Page 12 Set the main poles A ： Spread the tarp out (on the ground) where you plan to set up. B ： Place the two main poles on the ground extending from the center line. C ： Insert the tip of the main pole into ...
- Page 13 Set the main poles E ： Lay the ropes out at 45 degree angles. F ： Drive tent pegs into the ground. G ： Before pitching the main poles, loosen the rope tensioners. Drive pegs Loosen the tension 45° 45°...
- Page 14 Set the main poles A ： Pitch the main poles. B： Adjust the tension of the 4 ropes to make the center line and poles straight. C ： When the main poles and ropes are set up you should ...
- Page 15 Set the side poles A ： Insert tip of the side poles into the grommets on the side of the body and loop 3 m rope around the tip. B ： Drive tent pegs into the ground. C ： Adjust the tension of the ropes. *Do the same for both sides.
- Page 16 Peg down the 4th corners A ： Attach 3 m ropes to the grommets on all 4 corners. B： Drive tent pegs into the ground. C ： Adjust the tension of the ropes.
- Page 17 Set the Tarp Tail Use the Tarp Tail to set up close to another tent without It is a method to set your tent and tarp close to each other using the attached Tarp Tail. A ： Connect the Tarp Tail to the main body. B：...
- Page 18 Set the Tarp Tail If you don't use the Tarp Tail to set up a tent close to the tarp, the Tarp Tail can be used as a lantern hanger. A ： Connect the Tarp Tail along the inside of the tarp. B：...
- Page 19 ZANE ARTS , Inc. 716 8-13 Sh im auc hi, Mat s umo t o , N ag a n o 390 - 0851 inf o@zane art s .c om...
