Regulating electrical actuator + return by super-capacitor
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

+ RETURN BY SUPER-CAPACITOR TCR-02T-KT
FEATURES
The TCR-02T-KT electric actuator is intended for motorising ¼ turn valves with a torque of 15 Nm.
Double proportional control function 4-20mA + closing manoeuvre provided by a super-capacitor. With a compact
construction and plastic housing, it is especially well suited for motorising small dimensions ball valves. The actuator has
many advanced control functions which can be set from the screen. IP67 leak-tightness: to be used indoors and, possibly,
outdoors under a shelter. Manual control with a key.
AVAILABLE MODELS
Supply voltages: 230V AC, 24V AC/DC.
Control: 4-20 mA
LIMITS OF USE
IP Code
Ambient temperature
Service factor
MECHANICAL FEATURES
Gear box
Torque
Angle of rotation
Declutching
Override control
Torque (Nm)
Voltage
Adjustment signal
Feedback signal
Manoeuvring time (s)
ISO 5211:
ELECTRICAL FEATURES
Motor protection
Limit switches
Anti-condensation
Electrical connection
Voltage
Power (W)
Current (A)
Fuse protection (A)
Information given as an indication only, and subject to possible modifications
REGULATING ELECTRICAL ACTUATOR
IP 67
- 20°C / +60°C
S4-50%
treated steel pinions
15 Nm
90° +/- 2°
without
By key
15
24V AC - DC
95-265V AC-DC
4-20 mA
4-20 mA
15
F03/F04/F05 - star 11
Thermal switch
2 adjustable switches
integrated
PE M10 + 1.5m cable
24V AC - DC
95-265V AC-DC
36
1,5
0,035 - 0,09
5
SECTORIEL S.A.
45 rue du Ruisseau
38290 SAINT QUENTIN-FALLAVIER – FRANCE
Telephone: +33 4 74 94 90 70 - Fax: +33 4 74 94 13 95
www.sectoriel.fr
/ Email : sectoriel@sectoriel.fr
15
40
1
IP
ISO
9001
67
Pages
Ref.
FT2419 ENG
Rev.
Date
02/2020
1/7
