OWNERS
MANUAL
Model No.
45-03641
250 LB. ATV
BROADCAST SPREADER
CAUTION:
Read Rules for
• Safety
Safe Operation
and Instructions
• Assembly
Carefully
• Operation
• Maintenance
• Parts
the fastest way to purchase parts www.speedepart.com
PRINTED IN USA
FORM NO. 49857 (REV. 1/06)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-03641 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agri-Fab 45-03641

Summary of Contents for Agri-Fab 45-03641

  • Page 1 ™ OWNERS MANUAL Model No. 45-03641 250 LB. ATV BROADCAST SPREADER CAUTION: Read Rules for • Safety Safe Operation and Instructions • Assembly Carefully • Operation • Maintenance • Parts the fastest way to purchase parts www.speedepart.com PRINTED IN USA...

  • Page 2: Rules For Safe Operation

    Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when operating equipment. • Read the towing vehicle owners manual and towing vehicle safety rules. Know how to operate your tractor before using the broadcast spreader attachment.
  • Page 3 QTY. DESCRIPTION QTY. DESCRIPTION Hex Bolt, 5/16" x 1-3/4" Hex Bolt, 5/16" x 1-3/4" Hex Bolt, 5/16" x 1-3/4" Hex Bolt, 1/4" x 1-3/4" Hex Bolt, 1/4" x 1-3/4" Hex Bolt, 1/4" x 1-3/4" Hex Bolt, 1/4" x 2" Hex Bolt, 1/4" x 2" Hex Bolt, 1/4"...

  • Page 4: Tools Required For Assembly

    TOOLS REQUIRED FOR ASSEMBLY (1) Pliers (2) 7/16" Wrenches (2) 1/2" Wrenches (2) 9/16" Wrenches REMOVAL OF PARTS FROM CARTON Remove all parts and hardware packages from the carton. Lay out all parts and hardware and identify using the illustrations on pages 2 and 3. ASSEMBLY 1.
  • Page 5 (air valve facing out) and another 3/4" fl at washer (L) onto the end of the axle that has both the large and small holes. See fi gure 4. 10. Install a 1/8" x 1-1/2" cotter pin (N) into the small hole in the end of the axle.
  • Page 6 See fi gure 8. 19. Insert the fl ow control arm down through the slot in the fl ow control bracket. Assemble the small hole of the fl ow control link (V) to the fl ow control arm using a 1/4" x 1" hex bolt (E), a nylon washer (J) and a 1/4"...

  • Page 7: Carriage Bolt

    (R) NYLON WING NUT (K) 5/16" FLAT WASHER (J) NYLON WASHER (S) ADJUSTABLE STOP (F) 1/4" x 3/4" CARRIAGE BOLT FIGURE 12 24. Position the fl ow control mounting bracket (fi gure 13). a. Push on fl ow control arm until it locks in "OFF" position.

  • Page 8: Operation

    to the holes in the hitch tube shown at the top of fi gure 16. Use two 1/4" x 1-3/4" hex bolts (B) and 1/4" nylock hex nuts (G) tightened only fi nger tight. Attach the spreader hitch to your vehicle hitch. Check for interference with the spreader directly behind and out to both sides of the vehicle.

  • Page 9: Maintenance

    REFER CHARTS OVERLAP FIGURE 17 IMPORTANT: Application rates shown in the chart are affected by humidity and by the moisture content of the material (granular and pellet). Some minor setting adjustments may be necessary to compensate for this condition. APPLICATION CHART TYPE TYPE TYPE...
  • Page 10 21 22...
  • Page 11 REF. REF. REF. REF. PART PART PART PART QTY. QTY. QTY. QTY. 49414 49414 49414 Hopper Hopper Hopper 43882 43882 43882 43882 Rivet, Stainless Rivet, Stainless Rivet, Stainless Rivet, Stainless 65129 65129 65129 65129 Ass'y, Guide Closure Ass'y, Guide Closure Ass'y, Guide Closure Ass'y, Guide Closure 44462...

  • Page 12: Repair Parts

    REPAIR PARTS Agri-Fab, Inc. 809 South Hamilton Sullivan, IL. 61951 217-728-8388 © 2005 Agri-Fab, Inc. www.agri-fab.com...
