INTRODUCTION.
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
Before operating this projector, please read this manual carefully and completely.
This manual will provide you with the basic instructions for operation of the
projector. Installation, preliminary adjustments and procedures which require the
opening of the projector and contact with electrical components should be
performed by service personnel. For continued safe and reliable operation, use
only cables supplied by the manufacturer for power. Adhere to all notes and
warnings.
Features
Multi scan circuit automatically locks on video, superdata from 15 to 75 kHz
(XG75A) and graphics signals from 15 to 110 kHz (XG110LC) and 15 to 135
kHz (XG135LC).
You can interface video and high resolution RGB signals from various
computers, workstations and graphics boards.
8" CRTs with deflection angle 90 degrees produce a detailed picture with a
resolution of 2500 2000 (addressable).
Newly developed video output circuit makes possible 110 MHz of Video
Bandwidth (XG75A), 120 MHz (XG110LC) and 150MHz (XG135LC) with
1100 lumens peak light output (XG75A) and 1200 lumens (XG110/
XG135LC).
ECP lens produces an image with true color reproduction.
AKB circuit provides stable white balance.
Display size can be altered to accommodate any picture size from 60" to 300"
diagonal. In addition to ceiling mounting, floor, desk top and rear installations
are possible. (The ceiling mounting kits can be purchased as an optional item
for ceiling installation.)
Digital convergence provides high accuracy for projecting fine graphic
displays.
On-screen menus provide easy access to adjustment items.
ISS-6020/ISS-6020G interface allows 100 inputs.
Video system compatible with NTSC, PAL, SECAM and NTSC 4.43.
Up to 100 sources can be stored in digital memory.
Quick copy convergence for fast easy set up from one pre-set signal.
Built in self diagnostics for on-sight troubleshooting.
Built in test patterns such as "CROSS HAIR", "CROSS HATCH", "DOT",
"WINDOW" ,"ALL WHITE", "GRAY SCALE", and "H (FOCUS)" for
accurate setup.
Source information status display.
The SEQUENCER function allows the projector to automatically select input
signals one after another as programmed by the user.
Gamma Correction for improved Gray Scale and improved Gray Scale
Tracking.
