- Page 2 CONTENTS 1. PRODUCT INTRODUCTION ......................1 2. INSTALLATION PLANNING & CAUTIONS ..................1-3 3. TECHNICAL PARAMETER ......................... 3 4. WIRING DIAGRAM ..........................3 5. INSTALLATION DIMENSIONS ......................3 6. INSTALLATION INSTRUCTIONS ....................... 4 7. OPERATING INSTRUCTIONS......................5 8. MAINTENANCE AND CLEANING ...................... 5...
- Page 3 1. PRODUCT INTRODUCTION Air curtains are widely installed at the entrances of a supermarket, theater, meeting room, hotel, office room or storage room etc. They can reduce presence of insects, outside dust and unconditioned air into a conditioned space by forcing an air stream over the entire entrance to create a comfortable environment for you.
- Page 4 FIG 3 FIG 4 2.5 If you want to install the unit from ceiling, please purchase a suitable hanging kit. 2.6 Always disconnect, lock and tag power source before installing or servicing. Failure to disconnect power source can result in fire, shock or serious injury. 2.7 Please ensure the unit is installed in a firm place otherwise operating the unit may cause the wall or ceiling to become loose, shake and/or make noise.
- Page 5 3. TECHNICAL PARAMETER Rated Motor input Heater power Air volume Air velocity Noise Model Voltage power (W) L/H (KW) (m/s) level (dB) (V~Hz) DVSH3000WHS 230~50 1.5/3.0 The specifications are subject to change without notice due to product development. 4. WIRING DIAGRAM Internal wiring diagram of the air curtain: BN BL GN-YL...
- Page 6 6. INSTALLATION INSTRUCTIONS 6.1 Take out the installation bracket and fix it to the wall. A: If installing to a concrete, brick or any other hard wall, please refer to the installation dimension to determine the positions of where to affix screws.
- Page 7 7. OPERATING INSTRUCTIONS POWER SWITCH: The power switch is the main switch and it can be HEATER SWITCH: If only one of used to turn the fan and heater(s) on/off. To operate the fan setting the heater switches are on, the turn the power switch on, ensuring both heater switches are turned units heating power is 1.5kW off.
