K-20257T-CP
K- 20257T-2BZ
K- 20257T-BN
K-20257T-RGD
K-20257T-S3-CP
K-20257T-S5-CP
K-20258T-CP
安装之前
所有的资料是按最新出版的产品资料编写而成。
科勒公司保留任何时候不经通知即可改变产品特
性、包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项:
1. 一定要先彻底冲洗供水管以清除管道中的杂质,
使用水源为自来水或可供饮用水。
2. 请勿将强力及冲击施于产品，以免造成故障，
引起漏水。
3. 安装、清洁龙头时，切勿损伤感应窗口表面，
以免造成故障。
4. 如果是安装新的洗面盆，可将水龙头和排水组
件先安装到面盆上。
1298747-T01-B
柏诗台盆感应龙头（单冷型/不含电源盒/0.5GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)0.5GPM
柏诗台盆感应龙头-典雅黑（单冷型/不含电源盒/0.5GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)2BZ
柏诗台盆感应龙头-罗曼银（单冷型/不含电源盒/0.5GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)BN
柏诗台盆感应龙头-玫瑰金（单冷型/不含电源盒/0.5GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)RGD
柏诗台盆感应龙头（单冷型/不含电源盒/0.35GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)0.35GPM
柏诗台盆感应龙头（单冷型/不含电源盒/0.26GPM）
COMPOSED SENSOR FAUCET COLD ONLY(W/O P)0.26GPM
柏诗台盆感应龙头（冷热混合型/不含电源盒/0.5GPM）
COMPOSED SENSOR FAUCET MIXER(W/O P)0.5GPM
科勒（中国）投资有限公司
中国上海市闸北区江场三路158号 邮编：200436
制造商：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编:200444
Composed Sensor Faucet
BEFORE YOU BEGIN
All information is based on the latest product information
available at the time of publication, Kohler Co. reserves the
right to make changes to product characteristics, packaging,
or availability at any time without notice. Please deliver these
instructions for the consumer. They contain important
installation, maintenance and cleaning information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
Faucet is designed for tap water or potable water.
2. Handle the faucet with care to avoid damaged.
3. Do not damage the surface of sensing window when
installing or cleaning the faucet.
4. For new installations, install the faucet and drain to the
lavatory before installing the lavatory.
柏诗
COMPOSED
1
1
Advertisement
Related Manuals for Kohler K-20257T-CP
Summary of Contents for Kohler K-20257T-CP
- Page 1 BEFORE YOU BEGIN 安装之前 All information is based on the latest product information 所有的资料是按最新出版的产品资料编写而成。 available at the time of publication, Kohler Co. reserves the 科勒公司保留任何时候不经通知即可改变产品特 right to make changes to product characteristics, packaging, 性、包装或产品可供类型的权利。 or availability at any time without notice. Please deliver these 说明书包括重要的安装、保养及清洁方面的内容，...
- Page 2 5. As for DC type faucets, please pay special attention to 5. 对于直流龙头，安装时注意电池的正负极不能 insert direction matches battery poles. Tighten the battery 装反，电池盒盖要拧紧，防止电池受潮。 cover completely to prevent its exposure to moisture. 6. 对于交流龙头，安装时务必按照说明书的要求 6. For electric connection on AC faucets, carefully follow the installation instructions provided.
- Page 3 CAN BE MATCHED LAVATORY(Continued) 可搭配脸盆（续） K-2330-G KATHRYN ® 17'' Under Counter Lavatory K-2330-G 凯瑟琳17"台下台盆 K-2297 KATHRYN 21'' Under Counter Lavatory ® K-2297 凯瑟琳21"台下台盆 K-2889T VERTICYL ® Rectangular Under Counter Lavatory K-2889T 维克长方形台下台盆 K-2883 VERTICYL ® Round Under Counter Lavatory K-2883 维克圆形台下台盆...
- Page 4 ROUGH-IN DIMENSIONS(mm) 安装尺寸(毫米)(续） (Continued) 柏诗台盆感应龙头 柏诗台盆感应龙头 （交流电/冷热混合型） （交流电/单冷型） Whole metope Whole metope 123 140 123 140 AC/DC transformer AC/DC transformer 交流电源盒 交流电源盒 16305T-NA Drain 24484T-NA DC Power Unit AC/DC Transformer 排水组件 直流电源盒 交流电源盒 φ 41.2 φ 66.5 φ 31.75 φ Output: DC6V Input: AC220V Output: DC6V...
-
Page 5: Technical Specification
TECHNICAL SPECIFICATION 技术参数 电源：直流 4节5号碱性电池(LR06×4) Power: DC 4 pieces of AA size alkaline batteries AC 220V, 50/60Hz 交流 电压220V,频率50/60Hz Senser Duration: Less than 0.5s 检测时间：小于0.5秒 Shut-off Delay: 0.5~1s 关阀延时：0.5～1秒 Sensing Distance: Automatic adjustment 感应距离：自动调节 Flow Rate: 0.5GPM About 1.9L/min 流量： 0.35GPM About 1.4L/min 0.5GPM 约1.9L/min... - Page 6 注意： Note: Ensure cylinder install on water inlet. 三 安装直流电源盒 Install DC Power Unit 混水(Mixer) 1. Take battery box out, loosen screws (20) (20), insert 4 AA batteries per +/- (21) pole indication ( 21) on battery box cover. Fasten battery box 4节5 cover with screws.
- Page 7 如何安装交流电源盒 HOW TO INSTALL THE AC/DC TRANSFORMER 一个交流电源盒供一个感应龙头 One AC/DC transformer supply one touchless faucet Faucet 感应龙头 AC/DC transformer 交流电源盒 接220V交流电 Connect AC 220V Wire Tube Switch 穿线管 开关 一个交流电源盒供两个感应龙头 One AC/DC transformer supply two touchless faucets Faucet Faucet 感应龙头 感应龙头...
- Page 8 1. AC power unit (sticker on the back) should be installed in a dry place away from water. Customer should prepare wire tube and wire according to their requirement. Wire tube should be mounted into the wall. 0.5mm Suggested wire: AC connection wire adopts wires with 0.3 mm protecting layer or sleeve and the section should be ≥...
-
Page 9: Installation Checklist
Most cleaners may contain chemicals, such as ammonia, 面。许多清洁剂，比如氨水，去污粉及洁厕灵 chlorine, toilet cleaner etc. which could adversely affect the 等，会对电镀表面造成伤害，切忌使用。 finish and are not recommended for cleaning. Do not use abrasive cleaners or solvents on Kohler faucets and 有腐蚀性的清洁剂或溶剂不可使用于科勒的水龙 fittings. 头及其配件上。 用户须知... - Page 10 IMPORTANT CONSUMER INFORMATION 用户须知（续） (Continued) 如图示: As shown: (1) 快速闪烁，代表感应龙头正处于通电后 (1) Quick flashing means the faucet is in the period of adjusting sensing distance after power 的两分钟自动调节阶段。期间，安装者、使 on for 2 minutes. During these 2 minutes, please 用者不得干扰其自动调节，感应范围内不要 do not disturb auto adjustment or place objects 放置物体。...
-
Page 11: Troubleshooting
1 minute without switching off. Please contact with distributor or Kohler China Investment Co., Ltd., if the trouble remains after above-mentioned actions are taken.Please do not disassemble the other parts of the faucet freely except installing and replacing batteries. 1298747-T01-B... - Page 12 交流电源盒 1284602-SP 龙头 Adapter Hose 进水接头 1068120-SP 1279148-SP Connection Wire Kit Circlip 1248355-SP 卡箍 接头线组件 起泡器(仅用于）Aerator (only for )K-20257T-CP, K-20257T-2BZ, K-20257T-BN, 1284597-SP- ** K-20257T-RGD, K-20258T-CP Spout Body 1260117-SP 龙头主体 1286483-SP Cylinder Filter Assembly. 1258191-SP 1035611 -SP- ** Sensor Assy. Drain (Only for cold only) 起泡器(仅用于）...
- Page 13 产品中有害物质含量的说明 回收提示 本产品超过使用期限或经过维修无法正常使用后，不应随意丢弃，请交由有废弃电器电子产品处理资质的 企业处理，正确的处理方法请查阅国家或当地有关废旧电器电子产品处理的规定。 有害物质统计表 有害物质名称 部件名称 六价铬 多溴二苯醚 多溴联苯 铅(Pb） 镉（Cd） 汞（Hg） (Cr(VI)） （PBDE） （PBB） × ○ ○ ○ ○ ○ 外壳组件 ○ ○ ○ ○ × ○ 阀体组件 ○ × ○ ○ ○ ○ 控制盒组件 ○ ○ ○ ○...
- Page 14 :Indicate only partial product series contains this substance. Note: the information provided is based on the supplier data and Kohler inspection results. The product is designed not to hurt the environment. Under current technology, all hazardous materials have been used in the smallest amounts possible. Kohler will strive to reduce the use of these hazardous materials used in this product.
