General
• This appliance has a polarized plug (one blade is wider than the other). This plug will fit
in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not
change the plug in any way.
• Air beds are designed for temporary use and are NOT designed to be a replacement for
a traditional mattress.
• Make sure the area is flat, level, clean and free from sharp objects, and within reach of
an electrical outlet.
• To prevent puncture or damage to the air bed, never drag the air bed across the floor. Lift
the inflated air bed when moving or changing location.
• No air pump maintenance is required. Pump is removable.
• For cleaning use only clean cloth with mild soapy solution. Do not use any chemicals.
• In case of repairs, use only common PVC repair glue and patches. For flocked surfaces:
rub away the flocking material with an eraser first before applying the glue and/or patch.
10
Part Descriptions:
1. Pump holder frame
2. Pump removal tab
3. Cord compartment
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
Due to a policy of continuous product improvement, Intex reserves the right to change
specifications and appearance, which may result in updates to the instruction manual,
without notice.
SAVE THESE INSTRUCTIONS
(17IO) AP620D/AP620DP ELECTRIC PUMP ENGLISH 4.875" X 7.25" 05/29/2022
OPERATING INSTRUCTIONS

PARTS REFERENCE

11
8
1
7
4. AC power cord
5. Manual inflation port cap
6. Manual inflation port
7. Cord compartment cover
Page 2
3 4
2
5
6
9
8. Air passage
9. Control dial
10. Air bed front
11. Closed / Pump Off Position
