Controls
OSM
(On-Screen Manager) control buttons on the front of the monitor function
as follows:
Main Menu
Exits the OSM menu.
EXIT
CONTROL
Moves the highlighted
/
area left/right to select
one of the sub-menus.
Has no function.
CONTROL
–/+
Enters sub-menu.
SELECT
(FE770)
SELECT/
SBMODE
(FE771SB)
Resets all the controls within
RESET
the highlighted menu
to the factory setting.
NOTE:
When RESET is pressed in the main and sub-menu, a warning window will appear
allowing you to cancel the reset function.
NOTE:
In SB MODE (SuperBright Mode, FE771SB only), ON and OFF is functional when
the OSM is not displayed.
When OSM controls are activated, icons are displayed at the top of the menu.
If an arrow (➔) is displayed in a sub-menu, it indicates further choices are
available. To enter a sub, sub-menu, press PROCEED.
Brightness/Contrast Controls
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Degauss: Eliminates the buildup of stray magnetic fields which alter the correct
scan of the electron beams and affect the purity of the screen colors, focus and
convergence. When activated, your screen image will jump and waver a bit as
the screen is demagnetized.
Caution: Please allow a minimum of 20 minutes to elapse between uses of the
Degauss Control.

Size and Position Controls

Left/Right: Moves the image horizontally (left or right).
Down/Up: Moves the image vertically (up or down).
Narrow/Wide: Decreases or increases the horizontal size of the image.
Short/Tall: Decreases or increases the vertical size of the image.
MSFE770Manual.wpc
Sub-Menu
Exits to the OSM controls
main menu.
Moves the highlighted area
left/right to select one of the
controls.
Moves the bar in the – or +
direction to decrease or
increase the adjustment.
Has no function.
Resets the highlighted control
to the factory setting.
5
5
2/6/02, 4:53 PM
