- Page 1 Assembly Instructions October 25, 2022 Image Engineering GmbH & Co. KG · Im Gleisdreieck 5 · 50169 Kerpen · Germany T +49 2273 99991 - 0 · F +49 2273 99991 -10 · www.image-engineering.com...
-
Page 2: Table Of Contents
I INTRODUCTION CONTENT SETUP IQ-MONOPOD ....................3 Scope of Delivery ....................3 ................4 AST AND BASE INSTALLATION ................5 SHAPED HEIGHT ADJUSTMENT ................. 7 HORIZONTAL ADJUSTMENT BAR ....................9 HEIGHT ADJUSTMENT Image Engineering... -
Page 3: Setup Iq-Monopod
Headless screws • Horizontal-adjustment bar • 3-way gearhead • Allen-keys H-shaped height adjustment • Air pump Mast (ring with 3 stabilization arms Horizontal-adjustable bar Air pump 3 way gearhead Allen-keys Screw, flat washer, metal pipe T-base “front” “back” Image Engineering... -
Page 4: Mast And T- Base Installation
The three stabilization arms must be adjusted on the metal holders. Screw the holders to the down position (a), push the arm onto the holder (b), and screw the holder up until the construction is stable. Steps should be done by hand and not with a tool to avoid an over-tight adjustment. Image Engineering... -
Page 5: Shaped Height Adjustment
There are three holes with threads on the mast's upper side. These threads are used to anchor the H-shaped height adjustment to the mast. You will find another small white box with three headless screws with spiky ends and a small Allen key for this anchoring. Image Engineering... - Page 6 T-base) and twist both parts to each other until a collision cannot occur when turning the H-shaped height adjustment downwards. Avoid this issue by spending adequate time accurately adjusting all of the parts during the initial setup. Image Engineering...
-
Page 7: Horizontal - Adjustment Bar
HORIZONTAL ADJUSTMENT BAR The base of the horizontal-adjustment bar will have a rotary knob on top of the H-shaped height adjustment. The knob is delivered as an individual part. “back” “front” “back” “front” Image Engineering... - Page 8 The base of the horizontal-adjustment bar has a trapezoidal bar. You can fix the 3-way gearhead on the plate of horizontal-adjustment bar and slide the plate into the side of the horizontal-adjustment base. Horizontal-adjustable base Horizontal-adjustable bar “front” “back” Image Engineering...
-
Page 9: Height Adjustment
You can use the delivered air pump to make the monopod adjustable in height. Please note that the more air you fill in, the easier the monopod goes up, but then keep in mind that moving the monopod back down will be more challenging. See the image below to locate the connector: Connect Image Engineering...
