Contents

Your new NEC AccuSync LCD monitor box* should contain the following:
AccuSync LCD monitor with tilt base
Power Cord
Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male)
Setup Manual
Base Stand
Cable Holder
Setup Manual
Power Cord*
*
Remember to save your original box and packing material to transport or ship the monitor.
*1 Type of power cord included will depend on the where the LCD monitor is to be shipped.

Quick Start

To attach the Base Stand to the LCD Stand:
1. Attach the Base Stand to the Stand. The locking tabs on the Base Stand should fit
into the hole on the Stand (Figure S.1).
To attach the AccuSync LCD monitor to your system, follow these instructions:
1. Turn off the power to your computer.
2. For the PC or MAC with DVI digital output: Connect the DVI signal cable (not
included) to the connector of the display card in your system (Figure A.1).
Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to
the connector of the display card in your system (Figure A.2). Tighten all screws.
For the MAC: Connect the Macintosh cable adapter (not included) to the computer
and then attach the 15-pin mini D-SUB signal cable to the Macintosh cable adapter
(Figure A.3). Tighten all screws.
NOTE:
Some Macintosh systems do not require a Macintosh cable adapter.
DVI Signal Cable (not included)
Figure A.1
1
Video Signal Cable
Figure A.2
English-5
Cable Holder
Base Stand
AccuSync LCD monitor
(base stand not connected)
Figure S.1
Macintosh Cable Adapter
Figure A.3
(not included)
Stand
Base Stand
