Fluorescent Biological Microscope
BS-2036F2B(LED)/F2T(LED)
Instruction Manual
BS-2036F2B(LED)
BS-2036F2T(LED)
This manual is written for
BS-2036F2B(LED)/F2T(LED) Series LED fluorescent
biological
microscope.
To ensure the safety, obtain optimum performance and to familiarize you fully with the use of this
microscope, it is recommended strongly that you study this manual thoroughly before using the
microscope and retain this manual in an easily accessible place near the work desk for future
reference.
Advertisement
Table of Contents
Related Manuals for BestScope BS-2036F2B(LED)
Summary of Contents for BestScope BS-2036F2B(LED)
- Page 1 Fluorescent Biological Microscope BS-2036F2B(LED)/F2T(LED) Instruction Manual BS-2036F2B(LED) BS-2036F2T(LED) This manual is written for BS-2036F2B(LED)/F2T(LED) Series LED fluorescent biological microscope. To ensure the safety, obtain optimum performance and to familiarize you fully with the use of this microscope, it is recommended strongly that you study this manual thoroughly before using the microscope and retain this manual in an easily accessible place near the work desk for future reference.
-
Page 2: Table Of Contents
BestScope International Limited Contents Microscope Body Part ..................... ３ 1. Pars Name ......................３ 2. Specifications ....................... ４ 3. Installation ......................５ 4. Operation ......................５ 5. Image Collection ....................６ 6. Maintenance ......................７ Fluorescent Part ......................８ 1.Applications ......................８... - Page 3 BestScope International Limited Attentions！！ Purpose. This series microscopes are used only for microscopic observation, not available for other purpose, otherwise result in equipment damage. Disassembly only by the professionals. The microscope has been adjusted before shipping, Unprofessional-person should not disassemble and remove any other parts. Disassemble and remove any other parts will result in equipment damage.
-
Page 4: Microscope Body Part
BestScope International Limited Microscope Body Part BS-2036F2B(LED)/F2T(LED) series LED fluorescent biological microscopes are designed for college teaching, medical and clinical identification. The microscope with modern design, steady structure, convenient operation and clear image is suitable for observing various biological specimens, they are mostly applied in colleges and hospitals. -
Page 5: Specifications
BestScope International Limited 2. Specifications 2.1 Total magnifications Objective Total Magnifications 100X (Optional) Eyepiece 100X 200X 400X 1000X 160X 320X 640X 1600X 1.2 Objectives Infinite Plan Objectives are optional. Infinite Plan Numerical Objective Working Resolution (μm) Objectives Aperture (N.A.) Field Distance(mm) 0.10... -
Page 6: Installation
BestScope International Limited 3. Installation Please clean the operation desk before installation. Put out the microscope of the carton and put it on the desk. Make sure the supply voltage meets the instrument’s requirement and the power switch is off. -
Page 7: Image Collection
BestScope International Limited 4.1 Bright field operation process instruction 1) Turn power switch, Turn on Switch L, and turn Potentiometer K. adjust light Put the sample on stage ④, (open the clamp 2) Put the sample C, and put the sample into it), turn stage knob H to put the sample into optical path. -
Page 8: Maintenance
BestScope International Limited 6. Maintenance 6.1 Clean microscope 6.1.1 Don’t touch the lens with hand, Dust on lens should be cleaned by soft brush or absorbent cotton or cleaned by absorbent cotton, lens paper with the mixture of alcohol and ether (proportion 1:4). -
Page 9: Fluorescent Part
BestScope International Limited Fluorescent Part 1.Applications Some objects can emit a ray which wavelength is longer than that of the excitation light when irradiated. This ray is called fluorescence, and observers can study the objectives through fluorescence microscope using the phenomenon. -
Page 10: Instruction
BestScope International Limited 3.Instruction The fluorescence microscope is building-block structure, it includes main body, fluorescence conversion device, fluorescence excitation modules, fluorescence light source lamphouse and objective etc. Fluorescence device with 2 position can install two excitation modules and bright field observation position. Standard outfits: FL2-LED and special LED device for single. In addition, other excitation modules can be used as per user’s requirements. - Page 11 BestScope International Limited 14, 15 double ended connector wire for lamp box and power supply 16 two group LED light box 17 light box power socket 18 external power port 19 LED power box output socket 20 single group LED fluorescence light box...
-
Page 12: Fluorescence Device Operation
BestScope International Limited 5. Fluorescence Device Operation Please adjust microscope in bright field method and operate fluorescence attachment as follows: LED Fluorescence Device Operational Parts Marking Graphs 20 Lamp condenser adjusting lever 21 LED switch shift lever 22 brightness adjusting knob... - Page 13 BestScope International Limited ▲ Before perform fluorescence observation, locate the specimen with the transmission light first. ▲ To prevent the fluorescence from attenuation quickly, block the excitation light with barrier when preparing for fluorescence observation or photography. Only when observing or photographing, irradiate the specimen with the excitation light.
-
Page 14: Trouble Shooting
BestScope International Limited Trouble shooting In the period of using this series microscope, if there is any trouble occurs, please referring to the following sheet listed some common troubleshooting resolve them. Trouble Causation Remedy Plug is unreliable Plug in again... -
Page 15: Outfits
BestScope International Limited Outfits BS-2036 BS-2036 Item Specification F2B(LED) F2T(LED) Optical System Infinite Optical System ● ● Seidentopf Binocular Viewing Head, Inclined at 30°, 360° ● Rotatable, Interpupillary 48-75mm Viewing Head Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° ●... - Page 16 BestScope International Limited Cable Winding Device Package 42cm*28cm*45cm, 40cm*20cm*40cm, 12kg ● ● Note: ●Standard Outfit, ○Optional -１５-...
