Biological Microscope
This manual is for users of biological microscope BS-2010E. To ensure the safety, obtain optimum
performance and to familiarize yourself fully with the use of this microscope, it is recommended
strongly that you study this manual thoroughly before operating the microscope. Retain this
instruction manual in an easily accessible place near the microscope for further reference
Eyepiece
Objective
Stage
Condenser
Collector
BS-2010E
User Manual
BestScope International Limited
Bestscope International Limited
Monocular Head
Coarse Focusing
Fine
Knob
Brightness
Adjustment
Knob
Main
Switch
Knob
Focusing
1
Advertisement
Related Manuals for BestScope BS-2010E
Summary of Contents for BestScope BS-2010E
- Page 1 BS-2010E User Manual This manual is for users of biological microscope BS-2010E. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this microscope, it is recommended strongly that you study this manual thoroughly before operating the microscope. Retain this...
-
Page 2: Specification
Switch Knob 1 Appliance BS-2010E biological microscope is widely used in medical and hygienic establishments for conventional microscopic examination, general biologic, pathologic and bacteriological studies, clinical investigations and classroom demonstrations. Designed in a very modern way what can take convenient and safe to your operations. - Page 3 2.9 Diameter of Color Filter：Ø32mm 2.11 Illumination ： BS-2010 A、B、C、D:Incandescent Lamp Illumination 15W, Brightness Adjuseable BS-2010 E: LED Lamp Illumination 1W, Brightness Adjuseable 3 Outfits Component Specification BS-2010A BS-2010B BS-2010C BS-2010D BS-2010E Name Viewing Monocular Head, ● ● ● ●...
- Page 4 Bestscope International Limited 45° Eyepiece Wide Field ● ● ● ● ● Eyepiece WF10X Eyepiece ○ ○ ○ ○ ○ WF5X,P16X Eyepiece WF10X ○ ○ ○ ○ ○ with Pointer Objective 4X,10X ,40X(S) ● ● ● ● ● (Achromatic) 20X,60X ○...
- Page 5 Bestscope International Limited Incandescent Lamp Illumination ● ● ● ● ○ Brightness Adjustment LED Lamp 1W ○ ○ ○ ○ ● Brightness Adjustment Mirror ○ ○ ○ ○ ○ Focusingg Caaxial Coarse and Systerm Fine ● ● ● ● ●...
-
Page 6: Operation
Bestscope International Limited Avoid from the dust room. When it is not in use, please cover the microscope with dust cover. Please place the microscope in a stable situation without any 4） surging. b) Check the Input voltage: be sure the power supply voltage is accordant with the nominal input voltage which is signed outside the microscope, or it will bring a serious damage to the microscope. -
Page 7: Troubleshooting Guide
Bestscope International Limited in sequence, according to their magnifications, into the threaded holes of the nosepiece. Place the specimen in the center of the field of view, first use low power objective to find the specimen image and then observe it with high power objective, at the same time, adjust fine focusing knob until the image is clear. - Page 8 Bestscope International Limited Problem Cause Solution the edge of the field of The nosepiece is not in he located Turn right view has shadow or the position(objective is position(Turn objective brightness is uneven not in the center of optical light the optical path) center)）...
- Page 9 Bestscope International Limited There are stains on the incident Clean it up lens of the binocular tube size aperture Open it up diaphragm is too small The position of the condenser is Adjust the position too low One side of the image...
- Page 10 Bestscope International Limited 3、Electrical Part Problem Cause Solution Check the connection of the The lamp can’t light No power power cord when turning on the The bulb is not inserted Insert it correctly switch The bulb burns out Replace it...
