Wiring
Place the receiver on top of the downrod
assembly as shown.
Tip: If you have difficulty fitting the receiver
into place, make sure you have cut the excess
wires from the fan. See the Downrod section
for more details.
Refer to CAUTION c.1 on pg. 2
Receiver
M3644-01 • 02/01/17 • © 2017 Hunter Fan Company
Note: To connect the wires, hold
the bare metal leads together and
place a wire connector over them,
then twist clockwise until tight.
Using an orange wire connector
from the hardware bag:
Connect the 3 grounding wires
(green, green/yellow stripe, or bare
copper) coming from the ceiling,
downrod, and ceiling bracket.
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
9
www.HunterFan.com
1.888.830.1326
green/yellow stripe
