Hunter SIMPLEconnect Manual page 5

Ceiling Bracket
OFF
Make sure all four bumpers
are still attached.
For angled ceilings, point
opening toward peak.
If you are unable to do this,
call Technical Support at
1-888-830-1326.
Refer to warning w.1 on pg. 2
Use wood screws
(included) when securing
to support structure with
approved electrical outlet
box. Drill 9/64" pilot holes
in support structure to aid
in securing ceiling bracket
with hardware found in
the hardware bag.
5
M3644-01 • 02/01/17 • © 2017 Hunter Fan Company
www.HunterFan.com
Use machine screws
(provided with outlet
box) when securing to
existing ceiling fan-rated
outlet box. Make sure
it is securely installed
and is acceptable for fan
support of 31.8 kg (70 lbs)
or less.
To avoid possible electrical shock, before installing your fan,
disconnect the power by turning off the circuit breakers to
the outlet box associated with the wall switch location.
1.888.830.1326
