Gate Sensor

Installing batteries

The Gate Sensor requires 3 x AAA batteries
(not included) to operate.
1. Remove the screws from the battery
compartment cover, and then lift up the
cover.
2. Insert 3 new "AAA" alkaline batteries,
matching the polarity markings (+ and -)
inside the battery compartment.
3. Screw the battery compartment cover
back into place.

Mounting the Gate Sensor

The Gate Sensor can be easily
mounted to a surface next to a
gate/door using the included
mounting plate, screws and wall
plugs (if mounting to brick or
concrete). Be sure to install the
Gate Sensor high enough so it's
out of reach of small children.
Mounting the switch and magnet
The sensor switch and magnet are each fitted with an adhesive
strip. Stick the sensor on the gate/door frame (the stationary
part), and the magnet on the gate/door (the moving part) itself.
Press firmly against surface for 30 seconds to create a strong
bond. For proper detection, the sensor and magnet must be
aligned side by side with their arrows pointing to each other, no
more than 3/8" apart.
CAUTION: The Gate Sensor siren is extremely
loud! Protect your hearing by wearing earplugs.
SETTING UP
5
