AT A GLANCE

Thank you for choosing the Gate Alert Kit from Swann. It's the
ideal system to detect unwanted access into a restricted area
through the gate or door.
How does it work?
Basically, there are two parts to the Gate Alert Kit.
1. The Indoor Alarm Receiver works as an alarm buzzer. It
monitors for signals coming from the Gate Sensor, and
activates the alarm and channel LED indicator in response
to that signal.
2. The Gate Sensor consists of a wired switch and a magnet
which help safeguard a gate or door from being opened
without your knowledge. If the Delay button is not pressed
and the gate or door is opened, the Gate Sensor sounds its
built-in siren immediately and sends a signal to the Indoor
Alarm Receiver.

Getting to know your Gate Sensor

Siren
Status LED
Delay button
2
Sensor
Switch
Sensor
Magnet
Alignment
arrows
