Swann evo Quick Start Manual

Swann evo Quick Start Manual

Wi-fi video doorbell
Hide thumbs

Advertisement

Quick Links

Download this manual
evo
Wi-Fi Video Doorbell
EN Quick Start Guide
For other languages, scan QR Code below.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the evo and is the answer not in the manual?

Questions and answers

Related Manuals for Swann evo

Summary of Contents for Swann evo

  • Page 1 Wi-Fi Video Doorbell EN Quick Start Guide For other languages, scan QR Code below.
  • Page 2 Video Doorbell Overview Front Back Rubber cover Pull open from the bottom to access: Lens — SET (pair) button — RST button QR code — microSD card slot Microphone (for device — USB-C charging port pairing) Mounting Passive infrared bracket slots Infrared LEDs motion sensor (for night vision)
  • Page 3 Chime Overview Front Back LED indicator SET button Double-sided Speaker Battery mounting compartment tape area Installing Batteries BATTERY SAFETY INFORMATION Remove the battery compartment cover by sliding • Replace batteries at the same time. Solid blue it down. Do not mix new and old batteries or during charging Insert two new, high quality "AA"...
  • Page 4 Charging the Video Doorbell Your Video Doorbell is shipped partially charged. For optimum performance, fully charge it with the included USB-C charging cable before use. Open the rubber cover on the back of the Video Doorbell. Insert the smaller end of the charging cable into the USB-C port on the Video Doorbell, and the larger end into a USB power supply or wall charger.

  • Page 5: Installing The Microsd Card

    Installing the MicroSD card A microSD card (not included) is required for the Video Doorbell to record and store event clips locally. To install a microSD card (up to 128GB supported): Lift the rubber cover on the back of the Video Doorbell Insert the microSD card, with the gold contacts facing up, into the slot.
  • Page 6 Store® on your Android or iOS mobile device. Simply search for "Swann Security". Or, you can scan the QR code below to get the app. Open the Swann Security app and sign in, or tap “Not yet registered? Sign Up” to create your Swann Security account. Activate your Swann Security account by confirming the verification...
  • Page 7 Setting up the Video Doorbell Pair the Video Doorbell. In the Swann Security app, tap the Pair Device button on the screen (or tap the menu icon in the top left and select Pair Device). The app will now guide you through the pairing process to set up the Video Doorbell with your Wi-Fi network.
  • Page 8 Mounting the Video Doorbell The Video Doorbell can be mounted on the wall using the supplied mounting bracket, as shown below. Before mounting, ensure that the desired installation location has strong, reliable Wi-Fi reception. Use the app to stream live video from that location. If you encounter no video streaming issues, you’ve found a suitable spot for your device.

  • Page 9: Motion Detection

    When someone presses the Video Doorbell button, the Chime will sound, and you’ll receive a push notification from the Swann Security app. Simply open the notification to watch live video and see who’s at the door. You can also use the 2-way talk function to speak directly or play a preset message while in live view.
  • Page 10 Rebooting the Video Doorbell On rare occasions, it might be necessary to reboot the Video Doorbell if it becomes unresponsive. A simple reboot can often quickly resolve connectivity issues. To do this: Using a paper clip or a similar tool, press the RST button on the back of the Video Doorbell to power it off.
  • Page 11 Swann Security App Manual To learn more about using the Swann Security app, you can download the manual from the App Menu > User Manual or scan the QR code for your mobile device below. The app manual provides detailed information on how to view live video from the Video Doorbell, use 2-way talk, playback and download event recordings, configure camera settings, troubleshoot issues, access FAQs, and more.
  • Page 12 à une distance minimale de 20 cm entre le radiateur et votre corps. UK DECLARATION OF CONFORMITY — Technical Support Hereby, Swann Communications declares that this product is in compliance with the requirements for UKCA marking. The — Community Forums Declaration of Conformity can be obtained at uk.swann.com/compliance Model: SWIFI-SEVDBC ©...
