Stratasys SUPER DT3 Manual

Stratasys SUPER DT3 Manual

Cleaning station
Hide thumbs Also See for SUPER DT3:
Table of Contents

Advertisement

Quick Links

Download this manual
Cleaning Station
1
1
STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER DT3 and is the answer not in the manual?

Questions and answers

Related Manuals for Stratasys SUPER DT3

Summary of Contents for Stratasys SUPER DT3

  • Page 1 Cleaning Station STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 2 CS2P Clean Station– off-the-shelf system, for 350 & 500 platforms Large size • Active washing cell volume: 40 x 35 x 40 cm^3 ~ 60L . • Footprint: 91L x 76W x 100H cm^3 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 3 • Preparing the Solution • Introduction and Spec • Maintenance • Site Prep • Installation • Operating steps • Service • Hardware overview • Block Diagram STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 5 DT3 Part numbers • OBJ-01330 - SUPER DT3 CLEAN STATION 95V-105V - JP • OBJ-01331 - SUPER DT3 CLEAN STATION 120V - NA • OBJ-01332 - SUPER DT3 CLEAN STATION 220-240V - EMEA STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 6 • Pipe ¾ inch for the drain – should be provided by the customer • Suitable ¾ inch drain for the waste according to the local regulations • Power: STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 7: Operating Steps

    • DT3 can be used both for SU707 and SU706 models • It is to use SU705 – Pump Damage forbidden • It is to use SU706 with heavy or standard grid – Pump Damage forbidden STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 8: Hardware Overview

    Hardware Overview Front “panel” Button Name Function Toggle Timer set Home Returns to home Up/Down Arrow Increase/ Decrease time Home + Down Start/Stop STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 9 Hardware Overview Back Panel STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 10 Hardware Overview STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 11 Hardware Overview Manifold STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 12: Block Diagram

    Block Diagram 220V Fuse Line 110V Filter Fuse 100V 220V Pump Electrical Box Fans Main sw Level sw Controller Thermocouple STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 13: Installation

    • Connect a standard ¾" garden hose to the hose fitting at the back of the unit • Insert the drainage hose into a drain, sink, or container, according to local waste disposal regulations. STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 14 Installation Powering • Connect the power cable • Power on Fill in the solution according to the “Working with an Alkaline Cleaning Solution” Application Note STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 15 Servicing DT3 • All replaceable parts could be reached from the bottom of the DT3 • The back cover panel is attached by push reverts STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 16 Servicing Replaceable parts : • Electrical box • Controller • Fans • Level switches • Power switches • Pump • Fuses • Back panel with fans STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 17 Servicing STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 18 CS2P...

  • Page 19: Part Numbers

    Part numbers • OBJ-01340 – CS2P 60L Cleaning Station 220V-240V 50/60HZ (EMEA) • OBJ-01341 - CS2P 60L Cleaning Station 90V-110V 50/60HZ (NA&JP) STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 20 Solution preparation, measurement and evacuation is explained in the Application Notes. • Requires a periodic evacuation of the solution to “Hazard waste” site (for average user ~6-8 weeks) • Infrastructure needed: connection to water and drain. STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 21: Specifications

    Type I: 220V, 50/60Hz – for EMEA Power requirements Type II: 90-120V, 50/60Hz – for NA and Japan Regulatory compliance Chemical monitoring tested and found to be below threshold STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 22 • Place the CSIIP in a location with a minimum of 40 cm (16 inches) around the CSIIP at all times for proper ventilation. • Allow approximately 1.5 meters (59 in) in front of the CSIIP to enable easy STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 23 • 220V-240V devises will arrived WITHOUT a power connector • 90V-120V devises will arrive WITH US standard power connector • Residual Current Device (RCD) is needed STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 24 • If the temp and humidity are outside this spec the support removal process may be prolonged • The room ventilation system should change the air at least four times every hour STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 25 • CS2P can be used both for SU707 and SU706 models • It is forbidden to use SU705 models – can cause pump damage • It is forbidden to use HEAVEY and STANDART grids with SU706 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 26 Hardware Overview Operating Panel STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 27: Hardware Overview

    Hardware Overview Control panel Button Name Function Toggle Timer set Home Returns to home Up/Down Arrow Increase/ Decrease time Home + Down Start/Stop STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 28 Control Panel- Powering Sequence Selector SW – Power to Level SW Clean Part Controller Mag SW (part Selector SW - Pump Drain of the control Drain valve sw) STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 29 Hardware Overview STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 30 Hardware Overview • Manifold STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 31 Hardware Overview STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 32 Hardware Overview STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 33 Hardware Overview STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 34 Hardware Overview • Fuses STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 35 Block Diagram Elec Box Input Input Level Power Power Relays FUSE Filter Fans Clean Parts Selector From Mag SW Pump Drain On/Off Controller Thermocouple To Pump STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 36: Installation

    Installation Leveling the CS2P Connecting the Water Supply and Drainage Hoses STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 37 • a power cable plug intended for use in North America • a 220-V power cable with no plug attached. If necessary, attach the power plug required by local authorities STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 38 Servicing CS2P • All replaceable parts could be reached from the bottom of the DT3 • The back cover panel is attached by push reverts STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 39 Servicing CS2P Replaceable parts: • Electrical box • Controller • Fans • Level switch • Pump • Fuses • Back panel with fans STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

  • Page 40: Cleaning Process

    Cleaning Process...
  • Page 41 Add 1% Na2SiO3 (CAS 6834-92-0), according to the quantity shown in the table below. • Make sure the cleaning station pump is active, and mix the solution for 15 minutes. STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 42 Check solution Operate and Pause or stop saturation  part and wash wash (avg. of machine and lift thoroughly with neutralize and 7hrs) the basket water dispose STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 43 2. Stop stirring and immerse the hydrometer (provided in S/U Kit) into the solution 3. Collect value lower then 15% - the solution should be replaced STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 44 Main Steps: 1. Drain the tank 2. Clean the suction strainer and remove any material deposits 3. Remove the manifold 4. Clean the manifold with running water STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...
  • Page 45 THANK YOU STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY...

This manual is also suitable for:

Cs2pObj-01330Obj-01331Obj-01332Obj-01340Obj-01341
