Hercules
Wireless Crane Camera System
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hercules and is the answer not in the manual?

Questions and answers

Related Manuals for Scarlet Tech Hercules

Summary of Contents for Scarlet Tech Hercules

  • Page 1 Hercules Wireless Crane Camera System User Guide...

  • Page 2: Table Of Contents

    StreamLink Station Cabin AP Android Tablet Installation StreamLink station Set-up Hook Camera, Hook AP & Battery Pack Set-up Cabin AP and Android Tablet Set-up Hercules App Login Flow Login Page Home Page Single Camera Page Menu (Admin Account) Menu (Operator Account) Camera Configuration Page...

  • Page 3: Product List

    Product List Main Products (1) Hook Camera (with Waterproof LAN Cable 1.2M) (2) Hook AP (3) Battery Pack (4) StreamLink Station (5) Cabin AP (6) Android Tablet Antennas (7) 5 GHz Omnidirectional Antenna x 6pcs (8) 2.4 GHz Omnidirectional Antenna x 1pc Power Adapters and Cables / Cords (9) Power Cord 1.2M (Battery Pack to Hook AP) (10) Three-core Power Cord 50M (StreamLink Station)

  • Page 4: Product Overview

    Hercules system. At the same time, manager and supervisor benefit from the system by having access of remote worksite monitoring that is accessible anytime and anywhere from tablet via Hercules App (Free download on iOS and Android).

  • Page 5: Product Information

    Product Information 1. Hook Camera LAN Cable to Hook AP Magnets Magnets Lens Camera Image Sensor 1/2.8" CMOS Electronic Shutter 1/25s - 1/10000s Lens 2.8mm 110° Night Vision Starlight Technology Defog Digital Defog 180 x 122 x 122 mm (excluding cable) Dimension Weight 2.5kg (excluding cable)

  • Page 6: Hook Ap

    2. Hook AP LED Indicators for N-type Ports N-type Ports LAN Connection Status Magnets Magnets 3-pin Power Jack RJ45 Port to Hook Camera Dimension 265 x 265 x 82 mm (excluding antenna) Weight 2.2kg Wireless Technology Wi-Fi 5GHz (802.11 ac a/n) Antenna Omnidirectional 5GHz x2 I/O port...

  • Page 7: Battery Pack

    3. Battery Pack Magnets Magnets LCD Display for Battery Voltage Status LED Indicator for Power Status Power On/Off 3-pin Power Jack to Hook AP Power Jack for Charging Dimension 272 x 146 x 91 mm Weight Battery Type Molicel 26700 LiFePO4 Battery Volume 28000mAh Power Input...

  • Page 8: Streamlink Station

    4. StreamLink Station N-type Ports N-type Ports Magnets Magnets 3-pin Power Jack LED Indicators for LAN Connection Status RJ45 Port for Configuration Dimension 230 x 230 x 93 mm (excluding antenna) Weight 1.1kg Wireless Technology Wi-Fi 5GHz (802.11 ac a/n) Antenna Omnidirectional 5GHz x2 I/O port...

  • Page 9: Cabin Ap

    5. Cabin AP N-type Ports for 2.4GHz Antennas N-type Ports for 5GHz Antennas Power Jack LED Indicators for RJ45 Ports for PoE Cameras LAN Connection Status Dimension 269 x 239 x 82 mm (excluding antenna) Weight 2.6kg Wireless Technology Wi-Fi 5GHz (802.11 ac a/n) Wi-Fi 2.4GHz (802.11 b/g/n) Antenna Omnidirectional 5GHz x2...

  • Page 10: Android Tablet

    6. Android Tablet USB Type-C Port for Charging Power ON/OFF Volume UP/DOWN 3/4” Screw Hole for Mounting Bracket Dimension 247 x 193 x 40 mm (including TPU case & holder) Weight 700g Android 10 Display 10” IPS Touch Screen Resolution 1280 x 800 Wireless Connectivity Wi-Fi 2.4GHz (802.11 b/g/n)

  • Page 11: Installation

    Installation StreamLink Station Set-up Install one 5 GHz omnidirectional antennas on the N-type port of StreamLink station. Install another 5 GHz omnidirectional antenna on the 90° angle antenna transmitter which is pre-installed on the N-type port of StreamLink station. Wipe clean the crane jib surface. Mount the StreamLink station on the crane’s jib surface and then use safety rope to lock the StreamLink station to the jib for safety.
  • Page 12 Connect the 3-pin power cord (50 meters) to the StreamLink Station.
  • Page 13 Do wire stripping for the power cord and then connect to your DC 24V power source. POSITIVE + No Function NEGATIVE - Check the LED indicator on the StreamLink Station. If the PWR becomes green steady, it means the StreamLink Station is boot-up successfully. Description Definition Power status...

  • Page 14: Hook Camera, Hook Ap & Battery Pack Set-Up

    Hook Camera, Hook AP & Battery Pack Set-up Install two 5 GHz omnidirectional antennas on the 90-degree angle antenna transmitter which is pre-installed on the N-type port of Hook AP Wipe clean the crane hoist surface.
  • Page 15 Mount the Hook AP on the crane’s hoist surface and then use safety rope to lock the Hook AP to the crane hoist for safety Note: For better wireless signal quality, two antennas of Hook AP should be parallel to the ground. Mount the battery pack on the crane’s hoist surface and then use safety rope to lock the battery pack to the crane hoist for safety.
  • Page 16 Connect the battery pack and the Hook AP using 1.2 meters power cable. Connect to Battery Pack Connect to Hook AP Mount the Hook Camera on the crane’s hoist surface and then use safety rope to lock the Hook Camera to the crane hoist for safety. safety rope...
  • Page 17 Connect the Hook Camera and the Hook AP using waterproof LAN cable. LAN Cable from Hook Camera LAN Cable to Hook AP...
  • Page 18 Press the power ON button to supply battery power to Hook AP and Hook Camera. Check the LCD display and LED indicators on the battery pack. LED Indicator LCD Display Description Definition LCD Display Voltage information >=14V: Full charged <=12V: Low voltage, camera will shutdown LED Indicator Battery life status OFF: No power...
  • Page 19 Check the LED indicator on the hook AP. If PWR is green steady, it means the hook AP is boot-up successfully Description Definition Power status OFF: No power Steady Green: Power ON Data transmission status OFF: No data transmission Flashing Green: Data transmission is on-going Wireless signal strength between Hook OFF: No signal AP and StreamLink Station...

  • Page 20: Cabin Ap And Android Tablet Set-Up

    Cabin AP and Android Tablet Set-up Install two 5 GHz omnidirectional antennas on the 90-degree angle antenna transmitters which is pre-installed on the N-type ports on the rear side of cabin AP. Install one 2.4 GHz omnidirectional antenna to the port on the right side of cabin AP. Connect the cabin AP, power cable and power adapter, then plug the power.
  • Page 21 Check the LED indicator on the cabin AP. Description Definition Power status OFF: No power Steady Green: Power ON Data transmission status OFF: No data transmission Flashing Green: Data transmission is on-going Wireless signal strength between Cabin OFF: No signal AP and StreamLink Station S1 Steady Green: Very bad signal strength S3 &...
  • Page 22 Take the Android Tablet and remove the screen protector. Note: For better wireless signal quality, the distance between Android Tablet and Cabin AP should be less than 8 meters. Connect the Android Tablet, Charging Cable and Power Adapter, and then plug the power.
  • Page 23 <3> <4> <5> Launch the Hercules App and then you can start the operation. Note: After adding your camera to Hercules APP, please first sync the camera date & time with the Android Tablet via APP (Please do this first).

  • Page 24: Hercules App

    Login Page Item Name Description Account Select “admin” or “operator” account Account Access: • admin: Live-view, camera configuration and account management • operator: Live-view Password Input the password of Hercules App Login Select account and input password, then press login...

  • Page 25: Home Page

    : If the camera is powered by PoE *PoE (Power over Ethernet) means the power supplied directly from the Ethernet connection of Hercules system. Users do not need to charge from power plug Camera Name...

  • Page 26: Single Camera Page

    : If the camera is powered by PoE *PoE (Power over Ethernet) means the power supplied directly from the Ethernet connection of Hercules system. Users do not need to charge from power plug Camera Name...

  • Page 27: Menu (Admin Account)

    Menu (Admin Account) Item Name Description App Version Show the version of the Hercules App Video Streaming Go to Home page Camera Configuration Go to Camera Configuration page Account Management Go to Account Management page App Information Go to App Information page...

  • Page 28: Menu (Operator Account)

    Menu (Operator Account) Item Name Description App Version Show the version of Hercules App Video Streaming Go to Home page App Information Go to App Information page Log out Log out from current account...

  • Page 29: Camera Configuration Page

    Camera Configuration Page Name Item Description CAM # Camera number of this channel Camera Name Camera name assigned by admin account IP Address Camera IP address edition Add New Camera & Add or delete camera for this channel Delete Camera Camera Status Green: Video streaming On Red: Video streaming Off...

  • Page 30: Add New Camera Page

    Power Supply Select one power supply for new camera: Hercules Battery Pack: This camera is connected to Scarlet Hercules Hook AP & Battery Pack: The Hercu- les App can detect battery status. The battery level will be shown on home page Power Plug: This camera is powered by power adapt- er or other power source.

  • Page 31: Account Management Page

    Account Management Page Item Name Description Administrator Pass- Current Password: Input current password of account word Management “admin” (default password: 1234) New Password: Input new password New Password Again: Input new password one more time for confirmation Operator Password Current Password: Input current password of account Management “operator”...

  • Page 32: App Information Page

    App Information Page Item Name Description Information Scarlet Tech & Hercules information Menu Show the Menu to go to other pages Home Page Back to Home page...

  • Page 33: Account And Password Information

    Scarlet Sales team at info@scarlet.com.tw Q: Can I increase the camera’s storage memory size? A: No, Hercules Hook Camera has a default memory size setting. If you need more storage memory size, please email to Scarlet Sales team at info@scarlet.com.tw Q: Can I change the video recording resolution from 2K to HD to have more recording days? A: No, Hercules Hook Camera only supports 2K resolution for video recording.

  • Page 34: Warranty & Services

    Warranty & Services Warranty Conditions This instrument is guaranteed for one-year warranty against material or production defects, in accordance with our general sales conditions. During the warranty period the manufacturer reserves the right to decide either to repair or replace the product. Should you need any reason to return the instrument for repair or replacement, take prior agree- ments with the local distributor from whom you bought it.
  • Page 35 Scarlet Tech Co., Ltd. © 2020 Scarlet Tech Co., Ltd. All rights reserved. 4F-3, No. 347 , HePing E Rd, 2nd Sec, DaAn District, Taipei City 106, Taiwan info@scarlet.com.tw www.scarlet-tech.com version 220609...
