Regency Classic HI1150 Installation

Wood insert
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Model
Cordwood BTU's
Emissions (grams/hr) EPA Certified
Efficiency (EPA HHV)*
Efficiency (EPA LHV)
Flue Size
US Biomass Tax Rebate Eligible
Maximum Log Size
Firebox Size
NOTE: Available in metallic black or timberline brown enamel finish.
*US Biomass Tax Rebate eligibility is based on the HHV value being greater than or equal
to 75%.
DIMENSIONS WITH STANDARD FLUE ADAPTOR
Classic
HI1150 Wood Insert
™
Hi1150
55,000 BTU's
1.7 grams/hr
70%
75%
6" (152mm)
No
18" (457mm)
1.3 cu.ft.
25"
21-1/4"
39-13/16"
38-5/16"
24 1/4"
Door Width
6" (152mm) Diameter
6" (152mm) Diameter
STANDARD FLUE ADAPTOR (172-942)
OFFSET FLUE ADAPTOR (172-942)
2-7/8"
HI1150 Classic
Wood Insert |
™
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic HI1150 and is the answer not in the manual?

Questions and answers

Related Manuals for Regency Classic HI1150

Summary of Contents for Regency Classic HI1150

  • Page 1 Classic HI1150 Wood Insert ™ Model Hi1150 Cordwood BTU’s 55,000 BTU’s Emissions (grams/hr) EPA Certified 1.7 grams/hr Efficiency (EPA HHV)* Efficiency (EPA LHV) Flue Size 6" (152mm) US Biomass Tax Rebate Eligible Maximum Log Size 18” (457mm) Firebox Size 1.3 cu.ft. NOTE: Available in metallic black or timberline brown enamel finish.
  • Page 2 DIMENSIONS WITH OFFSET FLUE ADAPTOR 25” 6" (152mm) Diameter 6" (152mm) Diameter 6" (152mm) Diameter OFFSET FLUE ADAPTOR (172-942) 21-1/4” OFFSET FLUE ADAPTOR (172-946) OFFSET FLUE ADAPTOR (172-946) 39-13/16” 2-7/8” 38-5/16” | HI1150 Classic Wood Insert ™...

  • Page 3: Fireplace Specifications

    CLEARANCES MASONRY AND FACTORY BUILT FIREPLACES The minimum required clearances to combustible materials when installed into a masonry or factory built fireplace are listed below. Unit Adjacent Mantel Side Minimum Minimum From Top of Side Wall (to Top of Facing Facing Hearth Hearth Side...

  • Page 4: Installation Into Amasonry Fireplace

    Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. BEFORE INSTALLING YOUR INSERT Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) flue. 1. Please read this entire manual before you install and use your new wood insert.

  • Page 5: Installation Into Afactory Built Fireplace

    The system. In most cases the flue damper should - Blocking cooling air will overheat more you understand the way your Regency Insert also be removed to allow passage of the liner. the chimney...
